inverters
Goodrive300
capacity
Frequency
B.4 Motor connection data
Motor type
Voltage
Short-circuit
protection
Frequency
Frequency
resolution
Current
Power limit
Field weakening
point
Carrier frequency
B.4.1 EMC compatibility and motor cable length
To comply with the European EMC Directive (standard IEC/EN 61800-3), use the following
maximum motor cable lengths for 4 kHz switching frequency.
All frame sizes
With internal EMC filter
Second environment (category C3)
first environment (category C2)
Maximum motor cable length is determined by the drive's operational factors. Contact your
local INVT representative for the exact maximum lengths when using external EMC filters.
B.5 Applicable standards
The inverter complies with the following standards:
EN ISO 13849-1: 2008
IEC/EN 60204-1:2006
power connection as defined in IEC 60439-1 is 100 kA. The drive is
suitable for use in a circuit capable of delivering not more than 100
kA at the drive maximum rated voltage.
50/60 Hz ± 5%, maximum rate of change 20%/s
Asynchronous induction motor or synchronous permanent magnet
motor
0 to U1, 3-phase symmetrical, Umax at the field weakening point
The motor output is short-circuit proof by IEC 61800-5-1
0...400 Hz
0.01 Hz
Refer to Ratings
1.5 · PN
10...400 Hz
4, 8, 12 or 15 kHz(in scalar control)
Safety of machinery-safety related parts of control systems -
Part 1: general principles for design
Safety of machinery. Electrical equipment of machines. Part
274
Maximum motor cable length, 4 kHz
30
30
Appendix B
