INVT Goodrive 300 Operation Manual page 21

inverters
Goodrive300
Serial
No.
1 Keypad connections
2 Upper cover
3 Keypad
4 Cooling fan
5 Cardboard
Wire arrangement
6
interface
7 Name plate
8 Side cover
2
3
Fig 3-5 Product structure diagram
Name
Connect the keypad
Protect the internal parts and components
See Keypad Operation Procedure for detailed
information
See Maintenance and Hardware Fault Diagnose for
detailed information
The cardboard, with installation holes, is the same as
the behind cover of the machine and, so it is
convenient for the installation.
Connect to the control board and the drive board
See Product Overview for detailed information
Optional part. The side cover will increase the
protective degree of the inverter. The internal
temperature of the inverter will increase, too, so it is
necessary to derate the inverter at the same time
1
12
13
14
Illustration
20
Product overview
4
5
6
7
8
9
10
11
