7.17 Pulse counter

Goodrive300 series inverters support pulse counter which can input counting pulse through HDI
terminal. When the actual length is longer than or equal to the set length, the digital output terminal
can output length arrival pulse signal and the corresponding length will clear automatically.
Name
ACC time 1 0.0~3600.0s
DEC time 1 0.0~3600.0s
26:Traverse Pause(stop at the current
Digital input
frequency)
function
27:Traverse reset(return to the center
selection
frequency)
Traverse range 0.0~100.0%(relative to the set frequency)
Sudden jumping
frequency 0.0~50.0%(relative to the traverse range)
range
Traverse boost
0.1~3600.0s
time
Traverse
0.1~3600.0s
declining time
Detailed instruction of parameters
206
Basic operation instruction
Default
value
Depend
model
Depend
model
0.0%
0.0%
5.0s
5.0s
on
on
