INVT Goodrive 300 Operation Manual page 76

inverters
Goodrive300
Functio
Name
n code
Motor 1 low
frequency
P04.10
vibration
control factor
Motor 1 high
frequency
P04.11
vibration
control factor
Motor 1
vibration
P04.12
control
threshold
Motor 2 V/F
P04.13
curve setting
Motor 2
P04.14
torque boost
Motor 2
P04.15
torque
threshold
Motor 2V/F
P04.16 frequency
point 1
Motor 2V/F
P04.17 voltage point
1
P04.18 Motor 2V/F
Detailed instruction of parameters
the motor which is counted as below:
△f=f
-n*p/60
b
Of which, f is the rated frequency of the motor, its
b
function code is P02.01; n is the rated rotating speed
of the motor and its function code is P02.02；p is the
pole pair of the motor. 100.0% corresponds to the
rated slip frequency△f.
Setting range:0.0~200.0%
In the V/F control mode, current fluctuation may
occur to the motor on some frequency, especially the
motor with big power. The motor can not run stably
or overcurrent may occur. These phenomena can be
canceled by adjusting this parameter.
The setting range of P04.10:0~100
The setting range of P04.11:0~100
The setting range of P04.12:0.00Hz~P00.03(the
Max. frequency)
This group of parameters defines the V/F setting
means of Goodrive300 motor 2 to meet the features
of different loads. See P04.00~P04.12 for the
detailed function code instruction.
Note: P04 group contains two sets of V/F
parameters of the motor which cannot display
simultaneously. Only the selected V/F parameter can
be shown. The motor selection can be defined by
terminals function "the shift between motor 1 and
motor 2"
75
Function codes
Default Modif
value y
○
10
○
10
30.00
○
Hz
◎
0
○
0.0%
○
20.0%
○
0.00Hz
○
00.0%
○
00.00H
