inverters
Goodrive300
Function
code
Keypad data potentiometer
P08.43
UP/DOWN terminals
P08.44
UP terminals frequency
P08.45
P08.46
frequency changing ratio
P17.00
Ramp given frequency
P17.02
Name
integral ratio
control setting
changing ratio
DOWN terminals
Set frequency
Detailed instruction of parameters
1:Valid during running, cleared after
stopping
2:Valid during running, cleared after
receiving the stop command
LED thousands: ∧/∨ keys and digital
potentiometer Integral function
0:The Integral function is effective
1:The Integral function is ineffective
0.01~10.00s
0x00~0x221
LED ones: frequency control selection
0:UP/DOWN terminals setting effective
1:UP/DOWN terminals setting ineffective
LED tens: frequency control selection
0:Only effective when P00.06=0 or
P00.07=0
1:All frequency means are effective
2:When the multi-stage are priority, it is
ineffective to the multi-stage
LED hundreds: action selection when
stop
0:Setting effective
1:Effective in the running, clear after stop
2:Efective in the running, clear after
receiving the stop commands
0.01~50.00Hz/s
0.01~50.00 Hz/s
0.00Hz~P00.03
(the
frequency)
0.00Hz~P00.03
(the
frequency)
177
Basic operation instruction
Default
value
0.10s
0x000
0.50 Hz/s
0.50 Hz/s
Max.
output
0.00Hz
Max.
output
0.00Hz
