INVT Goodrive 300 Operation Manual page 183

inverters
Goodrive300
Function
code
P06.14 AO1 output selection
P06.15 AO2 output selection
HDO high-speed pulse
P06.16
P06.17 Lower limit of AO1 output
Corresponding AO1
P06.18
output to the lower limit
P06.19 Upper limit of AO1 output
P06.20 The corresponding AO1
Name
output selection
Detailed instruction of parameters
output
1: Open collector pole output
0:Running frequency
1:Set frequency
2:Ramp reference frequency
3:Running rotation speed
4:Output current (relative to the rated
current of the inverter)
5:Output current(relative to the rated
current of the motor)
6:Output voltage
7:Output power
8:Set torque value
9:Output torque
10:Analogy AI1 input value
11:Analogy AI2 input value
12:Analogy AI3 input value
13:High speed pulse HDI input value
14:MODBUS communication set value 1
15:MODBUS communication set value 2
16:PROFIBUS communication set value
1
17:PROFIBUS communication set value
2
18:Torque current(relative to the rated
current of the motor)
19:Pre-magnetizing current(relative to
the rated current of the motor)
20:Reserved
0.0%~P06.15
0.00V~10.00V
P06.13~100.0%
0.00V~10.00V
182
Basic operation instruction
Default
value
0.0%
0.00V
100.0%
10.00V
0
0
0
