INVT Goodrive 300 Operation Manual page 106

inverters
Goodrive300
Functio
Name
n code
dropping
control
The shifting
channel
P08.31 between
motor 1 and
motor 2
FDT1
electrical
level
P08.32
detection
value
FDT1
retention
P08.33
detection
value
FDT2
electrical
P08.34 level
detection
value
FDT2
P08.35 retention
detection
Detailed instruction of parameters
Setting range:0.00~50.00Hz
Goodrive300 supports the shift between two motors.
This function is used to select the shifting channel.
LED ones: shifting channel
0: terminal shifting; digital terminal is 35
1: MODBUS communication shifting
2: PROFIBUS communication shifting
3: Ethernet communication shifting
4: CAN communication shifting
LED tens: shifting enabling in operation
0: Disabled
1: Enabled
0x00~0x14
When the output frequency exceeds the
corresponding frequency of FDT electrical level, the
multi-function digital output terminals will output the
signal of "frequency level detect FDT" until the output
frequency decreases to a value lower than (FDT
electrical level—FDT retention detection value) the
corresponding frequency, the signal is invalid. Below
is the ware form diagram:
Setting range of P08.32: 0.00Hz~P00.03(the Max.
105
Function codes
Default Modif
value y
◎
0
50.00H
○
z
○
5.0%
50.00H
○
z
○
5.0%
