INVT Goodrive 300 Operation Manual page 63

inverters
Goodrive300
Functio
Name
n code
Start delay
P01.23
time
Delay time of
P01.24 the stop
speed
0Hz output
P01.25
selection
P02 Group Motor 1
P02.00 Motor type 1
Asynchronou
P02.01 s motor 1
rated power
Asynchronou
s motor 1
P02.02
rated
frequency
Asynchronou
P02.03
s motor 1
Detailed instruction of parameters
Setting range: 0.0~3600.0s (valid when P01.21=1)
The function determines the brake release after the
running command is given, and the inverter is in a
stand-by state and wait for the delay time set by
P01.23
Setting range: 0.0~60.0s
Setting range: 0.0~100.0 s
Select the output mode at 0Hz.
0: Output without voltage
1: Output with voltage
2: Output at DC braking current at stopping
0:Asynchronous motor
1:Synchronous motor
Note: Switch the current motor by the switching
channel of P08.31.
0.1~3000.0kW
0.01Hz~P00.03(the Max. frequency)
1~36000rpm
62
Function codes
Default Modif
value y
○
0.0s
●
0.0s
●
0
◎
0
Depend
◎
on
model
50.00H
◎
z
Depend
◎
on
