INVT Goodrive 300 Operation Manual page 79

inverters
Goodrive300
Functio
Name
n code
P05 Group Input terminals
HDI input
P05.00 type
selection
S1 terminals
P05.01 function
selection
S2 terminals
P05.02 function
selection
S3 terminals
P05.03 function
selection
S4 terminals
P05.04 function
selection
S5 terminals
P05.05 function
selection
S6 terminals
P05.06 function
selection
S7 terminals
P05.07 function
selection
Detailed instruction of parameters
0:HDI is high pulse input. See P05.49~P05.54
1:HDI is switch input. See P05.09
0: No function
1: Forward rotation operation
2: Reverse rotation operation
3: 3-wire control operation
4: Forward rotation jogging
5: Reverse rotation jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10:Increasing frequency setting(UP)
11:Decreasing frequency setting(DOWN)
12:Cancel the frequency change setting
13:Shift between A setting and B setting
14:Shift between combination setting and A setting
15:Shift between combination setting and B setting
16:Multi-stage speed terminal 1
17:Multi-stage speed terminal 2
18:Multi-stage speed terminal 3
19:Multi- stage speed terminal 4
20:Multi- stage speed pause
78
Function codes
Default Modif
value y
◎
0
◎
1
◎
4
◎
7
◎
0
◎
0
◎
0
◎
0
