INVT Goodrive 300 Operation Manual page 88

inverters
Goodrive300
Functio
Name
n code
P06.02 HDO output
Relay RO1
P06.03
output
Relay RO2
P06.04
output
Polarity
selection of
P06.05
output
terminals
Detailed instruction of parameters
1:In operation
2:Forward rotation operation
3:Reverse rotation operation
4: Jogging operation
5:The inverter fault
6:Frequency degree test FDT1
7:Frequency degree test FDT2
8:Frequency arrival
9:Zero speed running
10:Upper limit frequency arrival
11:Lower limit frequency arrival
12:Ready for operation
13:Pre-magnetizing
14:Overload pre-alarm
15: Underload pre-alarm
16:Completion of simple PLC stage
17:Completion of simple PLC cycle
18:Setting count value arrival
19:Defined count value arrival
20:External fault valid
21:Length arrival
22:Running time arrival
23:MODBUS communication virtual terminals output
24:PROFIBUS communication virtual terminals
output
25: Ethernet communication virtual terminals output
26: CAN communication virtual terminals output
27~30: Reserved
The function code is used to set the pole of the
output terminal.
When the current bit is set to 0, input terminal is
positive.
87
Function codes
Default Modif
value y
○
0
○
1
○
5
○
00
