INVT Goodrive 300 Operation Manual page 118

inverters
Goodrive300
Functio
Name
n code
The running
P10.25 time of step
11
Multi-step
P10.26
speed 12
The running
P10.27 time of step
12
Multi-step
P10.28
speed 13
The running
P10.29 time of step
13
Multi-step
P10.30
speed 14
The running
P10.31
time of step
14
Multi-step
P10.32
speed 15
The running
P10.33 time of step
15
P10.34 Simple PLC
Detailed instruction of parameters
When terminal 1, terminal 2, terminal 3, terminal
4=OFF, the frequency input manner is selected via
code P00.06 or P00.07. When terminal 1, terminal 2,
terminal 3, terminal 4 aren't off, it runs at multi-stage
which takes precedence of keypad, analog value,
high-speed pulse, PLC, communication frequency
input.
The relationship between terminal 1, terminal 2,
terminal 3, terminal 4 and multi-stage speed is as
following:
Terminal 1 OFF ON OFF ON OFF ON OFF ON
Terminal 2 OFF OFF ON ON OFF OFF ON ON
Terminal 3 OFF OFF OFF OFF ON ON ON ON
Terminal 4 OFF OFF OFF OFF OFF OFF OFF OFF
stage 0 1
Terminal 1 OFF ON OFF ON OFF ON OFF ON
Terminal 2 OFF OFF ON ON OFF OFF ON ON
Terminal 3 OFF OFF OFF OFF ON ON ON ON
Terminal 4 ON ON ON ON ON ON ON ON
Stage 8 9
Below is the detailed instruction:
2 3 4 5
10 11 12 13
117
Function codes
Default
value
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
6 7
0.0s
14 15
0x0000
Modif
y
○
○
○
○
○
○
○
○
○
○
