INVT Goodrive 300 Operation Manual page 182

inverters
Goodrive300
Set value
0 Running frequency
1
2 Ramp given frequency
3 Running rotation speed
Output current (relative to the
4
Output current (relative to the
5
6
7
8
9
10
11
12
13
MODBUS communication set
14
MODBUS communication set
15
PROFIBUS communication
16
PROFIBUS communication
17
Torque current(relative to the
18
rated current of the motor)
Exciting current (relative to
19 the rated current of the
20
Relative parameters list:
Function
code
P06.00
Function
Set frequency
inverter)
motor)
Output voltage
Output power
Set torque
Output torque
AI1
AI2
AI3
HDI
value 1
value 2
set value 1
set value 2
motor)
Reserved
Name
HDO output type
0~the Max. output frequency
0~ the Max. output frequency
0~ the Max. output frequency
0~2 times of the rated synchronous rotation speed of
the motor
0~2 times of the rated current of the inverter
0~2 times of the rated current of the inverter
0~1.5 times of the rated voltage of the inverter
0~2 times of the rated power
0~2 times of the rated current of the motor
0~2 times of the rated current of the motor
0~10V/0~20mA
0~10V/0~20mA
-10V~10V
0.00~50.00kHz
-1000~1000,1000 corresponds to 100.0%
-1000~1000,1000 corresponds to 100.0%
-1000~1000,1000 corresponds to 100.0%
-1000~1000,100 corresponds to 100.0%
0~2 times of the rated current of the motor
0~2 times of the rated current of the motor
Detailed instruction of parameters
0:Open collector pole high speed pulse
181
Basic operation instruction
Instructions
Default
value
0
