INVT Goodrive 300 Operation Manual page 91

inverters
Goodrive300
Functio
Name
n code
lower limit
Upper limit of
P06.19
AO1 output
The
correspondin
g AO1 output
P06.20
to the upper
limit
AO1 output
P06.21
filter time
Lower limit of
P06.22
AO2 output
Correspondi
ng AO2
P06.23
output to the
lower limit
Upper limit of
P06.24
AO2 output
Correspondi
ng AO2
P06.25
output to the
upper limit
AO2 output
P06.26
filter time
Lower limit of
P06.27
HDO output
Correspondi
ng HDO
P06.28
output to the
lower limit
P06.29 Upper limit of
Detailed instruction of parameters
When the analog output is current output, 1mA
equals to 0.5V.
In different cases, the corresponding analog output
of 100% of the output value is different. See each
application for detailed information.
A
O
10 V (20 m A )
0 .0 %
Setting range of P06.18 0.00V~10.00V
Setting range of P06.19 P06.17~100.0%
Setting range of P06.20 0.00V~10.00V
Setting range of P06.21 0.000s~10.000s
Setting range of P06.22 0.0%~P06.24
Setting range of P06.23 0.00V~10.00V
Setting range of P06.24 P06.22~100.0%
Setting range of P06.25 0.00V~10.00V
Setting range of P06.26 0.000s~10.000s
Setting range of P06.27 0.0%~P06.29
Setting range of P06.28 0.00~50.00kHz
Setting range of P06.29 P06.27~100.0%
Setting range of P06.30 0.00~50.00kHz
Setting range of P06.31 0.000s~10.000s
1 00.0%
90
Function codes
Default Modif
value y
○
100.0%
○
10.00V
○
0.000s
○
0.0%
○
0.00V
○
100.0%
○
10.00V
○
0.000s
○
0.00%
○
0.0kHz
○
100.0%
