The input interference filter can decrease the interference of the inverter to the surrounding
equipments.
Output interference filter can decrease the radio noise cause by the cables between the
inverter and the motor and the leakage current of the conducting wires.
Our company configured some filters for the convenient of the users.
D.7.1 Filter type instruction
Character
designation
A FLT:inverter filter seriee
Filter type
B
P:power supply filter
Voltage degree
C S2:signle phase 220Vac
04:3-phase 380Vac
D 3 bit rated current code "015" means 15A
Installation type
E L: Common type
H: High performance type
Utilization environment of the filters
A:the
F
61800-3:2004)
B:the
Detailed instruction
first envirtonment
first envirtonment
292
(IEC61800-3:2004)
(IEC61800-3:2004)
Appendix D
category C1 (EN
category C2 (EN
