Installing a Stand-Alone 5U Control Module

Scalar i500 User's Guide
None
Required tools:
Use this procedure to install a 5U library configuration:
1 Prepare the rack to hold modules, if you want to install your library
in a rack. See Installing the Library in a Rack
instructions on installing a rack-mount kit.
2 Make sure all tape drives have been removed from the control
module. See Adding, Removing, and Replacing Tape Drives
page 444 for instructions on removing tape drives.
3 Make sure all power supplies have been removed from the control
module. See Adding, Removing, and Replacing Power Supplies
page 420 for instructions on removing power supplies.
4 Open the library's I/E station door and access door. Lift the control
module and place it in the desired location.
5 If you are placing the control module in a rack, use the rack ears to
fasten the control module to the rack. For instructions, see
the Bottom Module in the Rack
6 If not already installed, install the library control blade (LCB) in the
control module. See
Blade and LCB Compact Flash Card
installing the LCB.
7 Add the tape drives to the module.
8 Install the power supplies. See
Power Supplies on page 420 for instructions on installing power
supplies.
9 Close the library's I/E station door and access door.
10 Connect all power cords and network data cables. See
Library on page 293.
11 Install module terminators in the top and bottom module terminator
connectors. See Cabling the Library
installing the module terminators.
12 Power on the library.
13 Configure the library using the operator panel Setup Wizard.
Chapter 12 Installing, Removing, and Replacing
Installing a Stand-Alone 5U Control Module
on page 433.
Removing and Replacing the Library Control
on page 408 for instructions on
Adding, Removing, and Replacing
on page 293 for information on
on page 423 for
on
on
Installing
Cabling the
329
