Quantum Scalar i500 Reference Manual

Tape library
Hide thumbs Also See for Scalar i500:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual, User Manual
Basic SNMP Reference Guide
Basic SNMP Reference Guide
Basic SNMP Reference Guide
Quantum Scalar i500 Tape Library
Quantum Scalar i500 Tape Library
6-01370-05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Scalar i500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Quantum Scalar i500

Summary of Contents for Quantum Scalar i500

  • Page 1 Basic SNMP Reference Guide Basic SNMP Reference Guide Basic SNMP Reference Guide Quantum Scalar i500 Tape Library Quantum Scalar i500 Tape Library 6-01370-05...
  • Page 2 Scalar i500 Basic SNMP Reference Guide, 6-01370-05, Ver. A, November 2008, Made in USA. Quantum Corporation provides this publication “as is” without warranty of any kind, either express or implied, including but not limited to the implied warranties of merchantability or fitness for a particular purpose. Quantum Corporation may revise this publication from time to time without notice.

  • Page 3: Table Of Contents

    Physical Drive Type ............. 15 Scalar i500 Basic SNMP Reference Guide...
  • Page 4 Physical Drive Location ............15 Physical Drive Firmware .
  • Page 5 Logical Library Storage Element Address ........
  • Page 6 Quantum Library MIB Content........

  • Page 7: About This Guide And Your Product

    Scalar i500 Tape Library User’s Guide. The Scalar i500 library supports SNMP by publishing a MIB that can be queried to obtain the status of the library and many of its individual components. You can obtain status information automatically by configuring the library to send alerts using SNMP traps, or you can obtain it on an ad-hoc basis by sending SNMP queries from your network management application.

  • Page 8: Other Documents You Might Need

    For further assistance, or if training is desired, contact Quantum: Global Call Handling For additional contact information: To open a Service Request: Quantum Corporation For the most updated information on Quantum Global Services, please visit www.quantum.com/support. 1-800-284-5101 www.quantum.com/support www.quantum.com/osr www.quantum.com www.quantum.com/...

  • Page 9: Description

    Accessing SNMP Information SNMP information can be obtained from the Scalar i500 using traps and GET queries. Using the information contained in this guide, library administrators can configure their framework application to generate alerts to receive Scalar i500 SNMP information.

  • Page 10: Snmpv3

    For secure access to the library using SNMP, disable SNMPv1 and SNMPv2c access from the remote web client and the operator panel. For more information, see either the Scalar i500 User’s Guide or the relevant Scalar i500 online help topics.

  • Page 11: Snmp Community Strings

    Go to Setup > Network Management > SNMP. Do one of the following: • Click the Authentication traps check box to enable authentication traps. • Remove the check from the Authentication traps check box to disable authentication traps. Click Apply. Scalar i500 Basic SNMP Reference Guide...
  • Page 12 Description...

  • Page 13: Mib Variables - Ipv6 Information

    Note that for some managed nodes, this object may take on only a subset of the values possible. Accordingly, it is appropriate for an agent to return a "wrongValue" response if a management station attempts to change this object to an inappropriate value. Scalar i500 Basic SNMP Reference Guide...

  • Page 14: Ipv6 Default Hop Limit

    IPv6 Default Hop Limit Name: ipv6DefaultHopLimit Type: OBJECT-TYPE OID: 1.3.6.1.2.1.55.1.2 Full path: iso(1).org(3).dod(6).internet(1).mgmt(2).mib- 2(1).ipv6MIB(55).ipv6MIBObjects(1).ipv6DefaultHopLimit(2) Module: IPV6-MIB Parent: ipv6MIBObjects Prev sibling: ipv6Forwarding Next sibling: ipv6Interfaces Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: INTEGER Status: current Max access: read-write Size list: 1: 0..255 Default values: 1: 64 Description: The default value inserted into the Hop Limit field of the IPv6 header of datagrams originated...

  • Page 15: Ipv6 Interface Description

    If this network interface operates over the data-link layer, then the value of this object refers to an instance of ifIndex [6]. • If this network interface operates over an IPv4 interface, the value of this object refers to an instance of ipAdEntAddr [3]. Scalar i500 Basic SNMP Reference Guide...

  • Page 16: Ipv6 Effective Maximum Transmission Unit

    • If this network interface operates over another IPv6 interface, the value of this object refers to an instance of ipv6IfIndex. • If this network interface is not currently operating over an active protocol layer, then the value of this object should be set to the OBJECT ID 0 0 .

  • Page 17: Ipv6 Interface Admin Status

    (or remains in the down(2) state). IPv6 Interface Operational Status Name: ipv6IfOperStatus Type: OBJECT-TYPE OID: 1.3.6.1.2.1.55.1.5.1.10 Full path: iso(1).org(3).dod(6).internet(1).mgmt(2).mib- 2(1).ipv6MIB(55).ipv6MIBObjects(1).ipv6IfTable(5).ipv6IfEntry(1).ipv6IfOperStatus(10) Module: IPV6-MIB Parent: ipv6IfEntry Prev sibling: ipv6IfAdminStatus Next sibling: ipv6IfLastChange Scalar i500 Basic SNMP Reference Guide...
  • Page 18 Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: INTEGER Status: current Max access: read-only Value list: 1: up(1) 2: down(2) 3: noIfIdentifier(3) 4: unknown(4) 5: notPresent(5) Description:The current operational state of the interface. The noIfIdentifier(3) state indicates that no valid Interface Identifier is assigned to the interface.

  • Page 19: Mib Variables - Drive Information

    Physical Drive Information Physical Drive Readiness Name: overallPhDriveReadinessStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.11.1 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalDrive(11).overallPhDriveReadinessStatus(1) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalDrive Next sibling: physicalDriveTable Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: OnlineState Status: current Scalar i500 Basic SNMP Reference Guide...

  • Page 20: Physical Drive Serial Number

    Max access: read-only Description: Overall drive readiness. Physical Drive Serial Number Name: phDriveSerialNumber Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.11.3.1.2 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalDrive(11).physicalDriveTable(3).physicalDriveEntry(1).phDriveSerialNumber(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalDriveEntry Prev sibling: phDriveIndex Next sibling: phDriveModel Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString...

  • Page 21: Physical Drive Vendor

    Parent: physicalDriveEntry Prev sibling: phDriveVendor Next sibling: phDriveLocation Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Drive generation type. Physical Drive Location Name: phDriveLocation Type: OBJECT-TYPE Scalar i500 Basic SNMP Reference Guide...

  • Page 22: Physical Drive Firmware

    OID: 1.3.6.1.4.1.3764.1.10.10.11.3.1.6 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalDrive(11).physicalDriveTable(3).physicalDriveEntry(1).phDriveLocation(6) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalDriveEntry Prev sibling: phDriveType Next sibling: phDriveFirmwareVersion Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Location of the drive in the library. Physical Drive Firmware...

  • Page 23: Physical Drive Library Serial Number

    Description: Serial number of the library that this drive resides in as reported in SCSI INQUIRY command. Physical Drive State Name: phDriveState Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.11.3.1.10 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalDrive(11).physicalDriveTable(3).physicalDriveEntry(1).phDriveState(10) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalDriveEntry Scalar i500 Basic SNMP Reference Guide...

  • Page 24: Physical Drive Health Status

    Status: current Max access: read-only Description: Device SCSI state. Physical Drive Health Status Name: phDriveRasStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.11.3.1.11 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalDrive(11).physicalDriveTable(3).physicalDriveEntry(1).phDriveRasStatus(11) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalDriveEntry Prev sibling: phDriveState Next sibling: phDriveNeedsCleaning Numerical syntax: Integer (32 bit) Base syntax: INTEGER...

  • Page 25: Physical Drive Interface Type

    Physical Drive SCSI LUN Name: phDriveScsiLun Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.11.3.1.14 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalDrive(11).physicalDriveTable(3).physicalDriveEntry(1).phDriveScsiLun(14) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalDriveEntry Prev sibling: phDriveInterfaceType Next sibling: phDriveScsiId Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Scalar i500 Basic SNMP Reference Guide...

  • Page 26: Physical Drive Scsi Id

    Max access: read-only Description: SCSI LUN of the device. Physical Drive SCSI ID Name: phDriveScsiId Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.11.3.1.15 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalDrive(11).physicalDriveTable(3).physicalDriveEntry(1).phDriveScsiId(15) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalDriveEntry Prevsibling: phDriveScsiLun Next sibling: phDriveLoads Numerical syntax: Integer (32 bit) Base syntax: Integer32...

  • Page 27: Physical Drive Physical Serial Number

    Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).fcPortTable(1).fcPortEntry(1).fcPortType(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: fcPortEntry Prev sibling: fcPortIndex Next sibling: fcPortWWNodeName Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: FCPortType Status: current Max access: read-only Description: Fibre Channel port type. Scalar i500 Basic SNMP Reference Guide...

  • Page 28: Fibre Channel Port World Wide Node Name

    Fibre Channel Port World Wide Node Name Name: fcPortWWNodeName Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.1.1.3 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).fcPortTable(1).fcPortEntry(1).fcPortWWNodeName(3) Module: ADIC-TAPE-LIBRARY-MIB Parent: fcPortEntry Prev sibling: fcPortType Next sibling: fcPortWWPortName Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: 8-byte value representing the drive’s World Wide Node Name.

  • Page 29: Fibre Channel Port Loop Id Mode

    Description: Loop ID mode for Fibre Channel drives; undefined for drives of other interface types. Controls negotiation of the port ID on the Fibre Channel connection. Fibre Channel Port ID Name: fcPortId Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.1.1.7 Scalar i500 Basic SNMP Reference Guide...

  • Page 30: Fibre Channel Port Negotiated Speed

    Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).fcPortTable(1).fcPortEntry(1).fcPortId(7) Module: ADIC-TAPE-LIBRARY-MIB Parent: fcPortEntry Prev sibling: fcPortLoopIdMode Next sibling: fcPortNegotiatedSpeed Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Max access: read-only Description: Port ID for fabric attached Fibre Channel drives; undefined for drives of other interface types.

  • Page 31: Fibre Channel Port Firmware Revision

    Status: current Max access: read-only Description:Firmware revision number/identifier for this Fibre Channel controller. Fibre Channel Port Frame Size Name: fcPortFrameSize Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.1.1.11 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).fcPortTable(1).fcPortEntry(1).fcPortFrameSize(11) Module: ADIC-TAPE-LIBRARY-MIB Parent: fcPortEntry Prev sibling: fcPortFWRev Scalar i500 Basic SNMP Reference Guide...

  • Page 32: Fibre Channel Port Drive Serial Number

    Max access: read-only Description: Fibre Channel frame size. Fibre Channel Port Drive Serial Number Name: fcPortDriveSerialNumber Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.1.1.12 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).fcPortTable(1).fcPortEntry(1).fcPortDriveSerialNumber(12) Module: ADIC-TAPE-LIBRARY-MIB Parent: fcPortEntry Prev sibling: fcPortFrameSize Next sibling: fcPortLogicalLibrarySerialNumber Numerical syntax: Octets Base syntax: OCTET STRING...

  • Page 33: Library Interfaces - Sas

    SAS Port RAS Status Name: sasPortRasStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.3.1.3 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).sasPortTable(3).sasPortEntry(1).sasPortRasStatus(3) Module: ADIC-TAPE-LIBRARY-MIB Parent: sasPortEntry Prev sibling: sasPortAddress Next sibling: sasPortNegotiatedSpeed Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: RASSubSystemStatus Scalar i500 Basic SNMP Reference Guide...

  • Page 34: Sas Port Negotiated Speed

    Status: current Max access: read-only Description: Currently not applicable. SAS Port Negotiated Speed Name: sasPortNegotiatedSpeed Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.3.1.4 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).sasPortTable(3).sasPortEntry(1).sasPortNegotiatedSpeed(4) Module: ADIC-TAPE-LIBRARY-MIB Parent: sasPortEntry Prev sibling: sasPortRasStatus Next sibling: sasPortFWRev Numerical syntax: Integer (32 bit) Base syntax: INTEGER...

  • Page 35: Sas Port Drive Serial Number

    Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.3.1.7 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).sasPortTable(3).sasPortEntry(1).sasPortLogicalLibrarySN(7) Module: ADIC-TAPE-LIBRARY-MIB Parent: sasPortEntry Prev sibling: sasPortDriveSerialNumber Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Logical library serial number. Scalar i500 Basic SNMP Reference Guide...

  • Page 36: Library Interfaces - Scsi

    Library Interfaces - SCSI SCSI Controller RAS Status Name: scsiControllerRasStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.2.1.2 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).scsiControllerTable(2).scsiControllerEntry(1).scsiControllerRasStatus(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: scsiControllerEntry Prev sibling: scsiControllerIndex Next sibling: scsiControllerSpeed Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: RASSubSystemStatus Status: current Max access: read-only Description: Currently not applicable.

  • Page 37: Scsi Controller Role

    10).libraryInterfaces(15).scsiControllerTable(2).scsiControllerEntry(1).scsiControllerIoCard(5) Module: ADIC-TAPE-LIBRARY-MIB Parent: scsiControllerEntry Prev sibling: scsiControllerRole Next sibling: scsiControllerMaxIds Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: SCSICtrlCardType Status: current Max access: read-only Description: Type of SCSI controller hardware. Scalar i500 Basic SNMP Reference Guide...

  • Page 38: Scsi Controller Maximum Ids

    SCSI Controller Maximum IDs Name: scsiControllerMaxIds Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.2.1.6 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).scsiControllerTable(2).scsiControllerEntry(1).scsiControllerMaxIds(6) Module: ADIC-TAPE-LIBRARY-MIB Parent: scsiControllerEntry Prev sibling: scsiControllerIoCard Next sibling: scsiControllerMaxLuns Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: INTEGER Status: current Max access: read-only Description: Maximum Number of IDs for this SCSI controller.

  • Page 39: Scsi Controller Firmware Revision

    Next sibling: scsiControllerDriveSerialNumber Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Firmware revision for this SCSI controller. SCSI Controller Drive Serial Number Name: scsiControllerDriveSerialNumber Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.15.2.1.10 Scalar i500 Basic SNMP Reference Guide...

  • Page 40: Scsi Controller Logical Library Serial Number

    Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).libraryInterfaces(15).scsiControllerTable(2).scsiControllerEntry(1).scsiControllerDriveSerialNumber(10 Module: ADIC-TAPE-LIBRARY-MIB Parent: scsiControllerEntry Prev sibling: scsiControllerFWRev Next sibling: scsiControllerLogicalLibrarySN Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Serial number of tape drive. SCSI Controller Logical Library Serial Number...

  • Page 41: Mib Variables - Library System Information

    Library IP Address Name: libraryIpAddress Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.1.1 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).tapeLibrarySystem(1).libraryIpAddress(1) Module: ADIC-TAPE-LIBRARY-MIB Parent: tapeLibrarySystem Next sibling: librarySNMPAgentDescription Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Scalar i500 Basic SNMP Reference Guide...

  • Page 42: Library Snmp Agent Description

    IPv6 address, then the IP address is displayed in IPv4 format (xxx.xxx.xxx.xxx). If the library only has an IPv6 address, then it will report an IPv6 format address. Library SNMP Agent Description Name: librarySNMPAgentDescription Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.1.2 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).tapeLibrarySystem(1).librarySNMPAgentDescription(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: tapeLibrarySystem Prev sibling: libraryIpAddress Next sibling: libraryName Numerical syntax: Octets...

  • Page 43: Library Vendor

    Module: ADIC-TAPE-LIBRARY-MIB Parent: tapeLibrarySystem Prev sibling: libraryVendor Next sibling: libraryDescription Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Library serial number. Library Description Name: libraryDescription Type: OBJECT-TYPE Scalar i500 Basic SNMP Reference Guide...

  • Page 44: Library Model

    OID: 1.3.6.1.4.1.3764.1.10.10.1.6 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).tapeLibrarySystem(1).libraryDescription(6) Module: ADIC-TAPE-LIBRARY-MIB Parent: tapeLibrarySystem Prev sibling: librarySerialNumber Next sibling: libraryModel Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Description of library. Library Model Name: libraryModel Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.1.7...

  • Page 45: Library Url

    Composed syntax: DisplayString Status: current Max access: read-only Description: URL of the library's management application. Library Product Name Name: libraryProductName Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.1.10 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).tapeLibrarySystem(1).libraryProductName(10) Module: ADIC-TAPE-LIBRARY-MIB Parent: tapeLibrarySystem Prev sibling: libraryURL Scalar i500 Basic SNMP Reference Guide...

  • Page 46: Library Firmware Version

    Status: current Max access: read-only Description: Product name of the library. Library Firmware Version Name: libraryFirmwareVersion Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.1.11 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).tapeLibrarySystem(1).libraryFirmwareVersion(11) Module: ADIC-TAPE-LIBRARY-MIB Parent: tapeLibrarySystem Prev sibling: libraryProductName Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString...

  • Page 47: Aggregated Main Door Status

    Aggregated Import Export (I/E) Door Status Name: aggregatedIEDoorStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.14.3 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalLibrary(14).aggregatedIEDoorStatus(3) Module: ADIC-TAPE-LIBRARY-MIB Parent: physicalLibrary Prev sibling: aggregatedMainDoorStatus Next sibling: numStorageSlots Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: IEDoorStatus Status: current Scalar i500 Basic SNMP Reference Guide...

  • Page 48: Number Of Storage Slogs

    Prev sibling: aggregatedIEDoorStatus Next sibling: numIESlots Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Max access: read-only Description: Number of storage slots. Number of I/E Slots Name: numIESlots Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.14.5 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).physicalLibrary(14).numIESlots(5)

  • Page 49: Number Of Physical Drives

    10).physicalLibrary(14).robot(30).robotState(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: robot Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: RoboticsReadiness Status: current Max access: read-only Description: Device SCSI state. Logical Library Number of Logical Libraries Name: numLogicalLibraries Scalar i500 Basic SNMP Reference Guide...

  • Page 50: Logical Library Name

    Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.13.1 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).logicalLibrary(13).numLogicalLibraries(1) Module: ADIC-TAPE-LIBRARY-MIB Parent: logicalLibrary Next sibling: logicalLibraryTable Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Max access: read-only Description: Number of existing logical libraries (partitions). Logical Library Name...

  • Page 51: Logical Library Model

    Base syntax: OCTET STRING Composed syntax: DisplayString Status: current Max access: read-only Description: Logical Library Model Logical Library Assigned LUN Name: logicalLibraryAssignedLun Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.13.2.1.5 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).logicalLibrary(13).logicalLibraryTable(2).logicalLibraryEntry(1).logicalLibraryAssignedLun(5) Module: ADIC-TAPE-LIBRARY-MIB Parent: logicalLibraryEntry Prev sibling: logicalLibraryModel Scalar i500 Basic SNMP Reference Guide...

  • Page 52: Logical Library Media Domain

    Max access: read-only Description: Assigned LUN of this library's (virtual) SCSI media changer. Logical Library Media Domain Name: logicalLibraryMediaDomain Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.13.2.1.6 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).logicalLibrary(13).logicalLibraryTable(2).logicalLibraryEntry(1).logicalLibraryMediaDomain(6) Module: ADIC-TAPE-LIBRARY-MIB Parent: logicalLibraryEntry Prev sibling: logicalLibraryAssignedLun Next sibling: logicalLibrarySupportedMediaTypes Numerical syntax: Octets...

  • Page 53: Logical Library State

    Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.13.2.1.9 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).logicalLibrary(13).logicalLibraryTable(2).logicalLibraryEntry(1).logicalLibraryNumSlots(9) Module: ADIC-TAPE-LIBRARY-MIB Parent: logicalLibraryEntry Prev sibling: logicalLibraryState Next sibling: logicalLibraryNumIE Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Max access: read-only Scalar i500 Basic SNMP Reference Guide...

  • Page 54: Logical Library Number Of I/E Slots

    Description: Number of storage elements. Logical Library Number of I/E Slots Name: logicalLibraryNumIE Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.13.2.1.10 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).logicalLibrary(13).logicalLibraryTable(2).logicalLibraryEntry(1).logicalLibraryNumIE(10) Module: ADIC-TAPE-LIBRARY-MIB Parent: logicalLibraryEntry Prev sibling: logicalLibraryNumSlots Next sibling: logicalLibraryNumTapeDrives Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32...

  • Page 55: Logical Library Storage Element Address

    Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Max access: read-only Description: First import/export element address of the partition. Logical Library Tape Drive Element Address Name: logicalLibraryTapeDriveElemAddr Type: OBJECT-TYPE Scalar i500 Basic SNMP Reference Guide...

  • Page 56: Logical Library Changer Device Address

    OID: 1.3.6.1.4.1.3764.1.10.10.13.2.1.14 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).logicalLibrary(13).logicalLibraryTable(2).logicalLibraryEntry(1).logicalLibraryTapeDriveElemAddr(14) Module: ADIC-TAPE-LIBRARY-MIB Parent: logicalLibraryEntry Prev sibling: logicalLibraryIEElemAddr Next sibling: logicalLibraryChangerDeviceAddr Numerical syntax: Integer (32 bit) Base syntax: Integer32 Composed syntax: Integer32 Status: current Max access: read-only Description: First data transfer element address of the partition.

  • Page 57: Blade Location

    Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: mandatory Max access: read-only Description: Blade location. Blade IP Name: bladeIP Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.1.1.3 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).bladeTable(1).bladeEntry(1).bladeIP(3) Module: ADIC-TAPE-LIBRARY-MIB Parent: bladeEntry Scalar i500 Basic SNMP Reference Guide...

  • Page 58: Blade World Wide Node Name

    Status: mandatory Max access: read-only Description: Blade IP address. Blade World Wide Node Name Name: bladeWWNodeName Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.1.1.4 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).bladeTable(1).bladeEntry(1).bladeWWNodeName(4) Module: ADIC-TAPE-LIBRARY-MIB Parent: bladeEntry Prev sibling: bladeIP Next sibling: bladeHealthCheckValue Numerical syntax: Octets Base syntax: OCTET STRING...

  • Page 59: Blade Health Check Level

    4: simpleDevice(3) 5: deviceReady(4) Description: Scrutiny level of health check function. Blade Health Check Interval Name: bladeHealthCheckInterval Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.1.1.7 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).bladeTable(1).bladeEntry(1).bladeHealthCheckInterval(7) Module: ADIC-TAPE-LIBRARY-MIB Parent: bladeEntry Prev sibling: bladeHealthCheckLevel Next sibling: bladeFWRev Scalar i500 Basic SNMP Reference Guide...

  • Page 60: Blade Firmware Revision

    Status: mandatory Max access: read-only Description: Health check interval in minutes. Blade Firmware Revision Name: bladeFWRev Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.1.1.8 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).bladeTable(1).bladeEntry(1).bladeFWRev(8) Module: ADIC-TAPE-LIBRARY-MIB Parent: bladeEntry Prev sibling: bladeHealthCheckInterval Next sibling: bladeSerialNumber Numerical syntax: Octets Base syntax: OCTET STRING...

  • Page 61: Blade Evps Enabled

    Blade Maximum Host Lun Name: bladeMaxHostLun Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.1.1.11 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).bladeTable(1).bladeEntry(1).bladeMaxHostLun(11) Module: ADIC-TAPE-LIBRARY-MIB Parent: bladeEntry Prev sibling: bladeEVPSEnabled Next sibling: bladeState Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: INTEGER Status: mandatory Scalar i500 Basic SNMP Reference Guide...

  • Page 62: Blade State

    Max access: read-only Description: The number of devices one host can see. Blade State Name: bladeState Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.1.1.12 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).bladeTable(1).bladeEntry(1).bladeState(12) Module: ADIC-TAPE-LIBRARY-MIB Parent: bladeEntry Prev sibling: bladeMaxHostLun Next sibling: blHPFLinkDownThreshold Numerical syntax: Integer (32 bit) Base syntax: INTEGER...

  • Page 63: Blade Host Port Failover Error Recovery Mode

    Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: FcHPFRecoveryType Status: mandatory Max access: read-only Description: Used to set the global recovery mode for failures that happen due to Link Down errors. Values: returnToActive(0), returnToStandby(1), requiresIntervention(2). Scalar i500 Basic SNMP Reference Guide...

  • Page 64: Blade Dev Entry

    Blade Dev Entry Blade Device Index Name: blDevIndex Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.2.1.1 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blDevTable(2).blDevEntry(1).blDevIndex(1) Module: ADIC-TAPE-LIBRARY-MIB Parent: blDevEntry Next sibling: blDevUID Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: INTEGER Status: mandatory Max access: read-only Description: MIB table index.

  • Page 65: Blade Device Vendor

    Next sibling: blDevProduct Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: mandatory Max access: read-only Size list: 1: 8 Description: Device vendor. Blade Device Product Name: blDevProduct Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.2.1.5 Scalar i500 Basic SNMP Reference Guide...

  • Page 66: Blade Device Serial

    Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blDevTable(2).blDevEntry(1).blDevProduct(5) Module: ADIC-TAPE-LIBRARY-MIB Parent: blDevEntry Prev sibling: blDevVendor Next sibling: blDevSerial Numerical syntax: Octets Base syntax: OCTET STRING Composed syntax: DisplayString Status: mandatory Max access: read-only Size list: 1: 16 Description: Device product identifier. Blade Device Serial...

  • Page 67: Blade Device Lun

    Max access: read-only Description: SCSI logical unit number of the device. Blade Device Controller Index Name: blDevCtlrIndex Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.2.1.9 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blDevTable(2).blDevEntry(1).blDevCtlrIndex(9) Module: ADIC-TAPE-LIBRARY-MIB Parent: blDevEntry Prev sibling: blDevLun Next sibling: blDevFWRev Scalar i500 Basic SNMP Reference Guide...

  • Page 68: Blade Device Firmware Revision

    Max access: read-only Description: Index of this device's controller in the controller’s MIB table and type-specific controller tables. Blade Device Firmware Revision Name: blDevFWRev Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.2.1.10 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blDevTable(2).blDevEntry(1).blDevFWRev(10) Module: ADIC-TAPE-LIBRARY-MIB Parent: blDevEntry Prev sibling: blDevCtlrIndex Next sibling blDevTargetLun...

  • Page 69: Blade Controller Table

    Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blCtlrTable(3).blCtlrEntry(1).blCtlrType(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: blCtlrEntry Prev sibling: blCtlrIndex Next sibling: blCtlrChannelMask Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: InterfaceType Status: mandatory Max access: read-only Description: Communication interface type. Scalar i500 Basic SNMP Reference Guide...

  • Page 70: Blade Controller Channel Mask

    Blade Controller Channel Mask Name: blCtlrChannelMask Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.3.1.3 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blCtlrTable(3).blCtlrEntry(1).blCtlrChannelMask(3) Module: ADIC-TAPE-LIBRARY-MIB Parent: blCtlrEntry Prev sibling: blCtlrType Numerical syntax: Gauge (32 bit) Base syntax: Gauge Composed syntax: Gauge Status: mandatory Max access: read-write Description: Specifies access permissions for this initiator in bits 0 through 18, as follows:...

  • Page 71: Blade Fibre Channel Controller Entry

    Blade Fibre Channel Controller Maximum Speed Name: blFcCtlrMaxSpeed Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.4.1.2 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blFcCtlrTable(4).blFcCtlrEntry(1).blFcCtlrMaxSpeed(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: blFcCtlrEntry Prev sibling: blFcCtlrStatus Next sibling: blFcCtlrWWPortName Numerical syntax: Gauge (32 bit) Base syntax: Gauge Composed syntax: Gauge Status: mandatory Scalar i500 Basic SNMP Reference Guide...

  • Page 72: Blade Fibre Channel Controller World Wide Port Name

    Max access: read-only Description: Maximum transfer speed in MBytes per second. Blade Fibre Channel Controller World Wide Port Name Name: blFcCtlrWWPortName Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.4.1.3 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blFcCtlrTable(4).blFcCtlrEntry(1).blFcCtlrWWPortName(3) Module: ADIC-TAPE-LIBRARY-MIB Parent: blFcCtlrEntry Prev sibling: blFcCtlrMaxSpeed Next sibling: blFcCtlrLoopID Numerical syntax: Octets...

  • Page 73: Blade Fibre Channel Controller Loop Id Mode

    Next sibling: blFcCtlrConnectionOptions Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: FibrePortMode Status: mandatory Max access: read-only Description: Fibre Channel port mode. Blade Fibre Channel Controller Connection Options Name: blFcCtlrConnectionOptions Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.4.1.7 Scalar i500 Basic SNMP Reference Guide...

  • Page 74: Blade Host Table

    Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blFcCtlrTable(4).blFcCtlrEntry(1).blFcCtlrConnectionOptions(7) Module: ADIC-TAPE-LIBRARY-MIB Parent: blFcCtlrEntry Prev sibling: blFcCtlrPortMode Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: FibreConnOptions Status: mandatory Max access: read-only Description: Connection options for ISP2200 FC chip. Values 4 – 8 are reserved.

  • Page 75: Blade Host Name

    Max access: read-only Size list: 1: 0..32 Description: Name for this initiator. Blade Host Type Name: blHostType Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.5.1.4 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blHostTable(5).blHostEntry(1).blHostType(4) Module: ADIC-TAPE-LIBRARY-MIB Parent: blHostEntry Prev sibling: blHostName Next sibling: blHostPortID Scalar i500 Basic SNMP Reference Guide...

  • Page 76: Blade Host Port Id

    Size list: 1: 0..32 Description: The type of host that is connected to the blade. Blade Host Port ID Name: blHostPortID Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.5.1.5 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blHostTable(5).blHostEntry(1).blHostPortID(5) Module: ADIC-TAPE-LIBRARY-MIB Parent: blHostEntry Prev sibling: blHostType Next sibling: blHostITLData Numerical syntax: Octets...

  • Page 77: Blade Host Lun Map

    Blade Host Port Failover Map Virtual Port Name: blHPFMapVirtualPort Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.6.1.1 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blHPFMapTable(6).blHPFMapEntry(1).blHPFMapVirtualPort(1) Module: ADIC-TAPE-LIBRARY-MIB Parent: blHPFMapEntry Next sibling: blHPFMapPrimaryPort Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: INTEGER Scalar i500 Basic SNMP Reference Guide...

  • Page 78: Blade Host Port Failover Map Primary Port

    Port), but will be zero if host port failover is not configured. Blade Host Port Failover Map Primary Port Name: blHPFMapPrimaryPort Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.6.1.2 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blHPFMapTable(6).blHPFMapEntry(1).blHPFMapPrimaryPort(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: blHPFMapEntry Prev sibling: blHPFMapVirtualPort Next sibling: blHPFMapStandbyList Numerical syntax: Integer (32 bit)

  • Page 79: Blade Host Port Failover Map Active Port

    OID: 1.3.6.1.4.1.3764.1.10.10.16.7.1.1 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blHPFPhysicalTable(7).blHPFPhysicalEntry(1).blHPFPhysicalPort(1) Module: ADIC-TAPE-LIBRARY-MIB Parent: blHPFPhysicalEntry Next sibling: blHPFPhysicalPortFailureType Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: INTEGER Status: mandatory Max access: read-only Description: The physical FC port index. Scalar i500 Basic SNMP Reference Guide...

  • Page 80: Blade Host Port Failover Physical Port Failure Type

    Blade Host Port Failover Physical Port Failure Type Name: blHPFPhysicalPortFailureType Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.16.7.1.2 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).bladeInterfaces(16).blHPFPhysicalTable(7).blHPFPhysicalEntry(1).blHPFPhysicalPortFailureType(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: blHPFPhysicalEntry Prev sibling: blHPFPhysicalPort Next sibling: blHPFPhysicalPortCurrentState Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: FcHPFPortFailType Status: mandatory Max access: read-only Description: If this physical port failed, this field provides the type of failure.
  • Page 81 Parent: blHPFPhysicalEntry Prev sibling: blHPFPhysicalPortCurrentState Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: Boolean Status: mandatory Max access: read-only Description: Does this physical port require intervention? Values: 1 = true; 2 = false. Scalar i500 Basic SNMP Reference Guide...
  • Page 82 MIB Variables - Library System Information...

  • Page 83: Mib Variables - Ras Subsystem

    Parent: rasSubSystem Next sibling: coolingStatus Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: RASSubSystemStatus Status: current Max access: read-only Description: Indicates overall power supply status. Cooling Status Name: coolingStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.12.2 Scalar i500 Basic SNMP Reference Guide...

  • Page 84: Control Status

    Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).rasSubSystem(12).coolingStatus(2) Module: ADIC-TAPE-LIBRARY-MIB Parent: rasSubSystem Prev sibling: powerStatus Next sibling: controlStatus Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: RASSubSystemStatus Status: current Max access: read-only Description: Indicates overall cooling fans status. Control Status Name: controlStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.12.3...

  • Page 85: Robotics Status

    Numerical syntax: Integer (32 bit) Base syntax: INTEGER Composed syntax: RASSubSystemStatus Status: current Max access: read-only Description: Indicates overall robotics status. Media Status Name: mediaStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.12.6 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).rasSubSystem(12).mediaStatus(6) Module: ADIC-TAPE-LIBRARY-MIB Parent: rasSubSystem Scalar i500 Basic SNMP Reference Guide...

  • Page 86: Drive Status

    Status: current Max access: read-only Description: Indicates overall media status. Drive Status Name: driveStatus Type: OBJECT-TYPE OID: 1.3.6.1.4.1.3764.1.10.10.12.7 Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).adic(3764).storage(1).library(10).tapeLibraryMIB( 10).rasSubSystem(12).driveStatus(7) Module: ADIC-TAPE-LIBRARY-MIB Parent: rasSubSystem Prev sibling: mediaStatus Next sibling: operatorActionRequest Numerical syntax: Integer (32 bit) Base syntax: INTEGER...
  • Page 87 Base syntax: INTEGER Composed syntax: INTEGER Status: current Max access: read-only Value list: 1: yes(1); 2: no(2). Description: Yes, if operator action is required. Scalar i500 Basic SNMP Reference Guide...
  • Page 88 MIB Variables - RAS Subsystem...

  • Page 89: Snmp Traps

    This section describes the basic set of Simple Network Management Protocol (SNMP) system status traps issued by the library. Traps pertain to the entire library, not specific modules or partitions. The Scalar i500 only supports SNMP v1 traps as defined by RFC 1157. Note Traps defined in the Tape Library Management Information Base (MIB) are issued with enterprise OID “Quantum Tape Library MIB”, which resolves to 1.3.6.1.4.1.3764.1.10.10.
  • Page 90 Table 1 Status Traps (Continued) Trap ID Trap roboticsNotReady logicalLibraryStateChange connectivityStatusChange controlStatusChange coolingStatusChange drivesStatusChange mediaStatusChange a. The library issues a trap whenever the aggregate state of one of the Reliability, Availability, and Serviceability (RAS) status groups changes. Listening for these traps (rather than querying for them) is the preferred method of monitoring the health of the library.
  • Page 91 The library issues a trap whenever the aggregate state of one of the Reliability, Availability, and Serviceability (RAS) status groups changes. Listening for these traps (rather than querying for them) is the preferred method of monitoring the health of the library. Scalar i500 Basic SNMP Reference Guide Description RAS Status Change: Power Indicates that the status of the power subsystem has changed.
  • Page 92 SNMP Traps...

  • Page 93: A Mibs Implemented

    The library requires five Management Information Bases (MIBs): the Quantum Tape Library MIB and four standard SNMP MIBs. Quantum Tape Library MIB The Quantum Tape Library MIB provides the following information: • System identification (library model and serial number) •...

  • Page 94: Quantum Library Mib Content

    -- Copyright (c) 2005-2008 by Quantum Corporation -- All rights reserved. -- **************************************************** -- Glossary of terms -- RAS : Reliability, Accessibility -- EVPS: Extended Virtual Private SAN (the Quantum/ADIC Masking and Mapping Feature) ADIC-TAPE-LIBRARY-MIB DEFINITIONS ::= BEGIN IMPORTS NOTIFICATION-TYPE, MODULE-IDENTITY, enterprises,...
  • Page 95 OBJECT IDENTIFIER ::= { tapeLibraryMIBNotificationPrefix 0 } -- Textual conventions FCPortType ::= TEXTUAL-CONVENTION STATUS current DESCRIPTION "Port type qualifier." SYNTAX INTEGER { nPort( 1 ), nlPort( 2 ), fPort( 3 ), flPort( 4 ), unknown( 5 ) Scalar i500 Basic SNMP Reference Guide...
  • Page 96 SCSICtrlSpeed ::= TEXTUAL-CONVENTION STATUS current DESCRIPTION "SCSI Speed." SYNTAX INTEGER { async(0), fast(1), ultra(2) , ultra80(3) , ultra160(4) , ultra320(5), ultra640(6), unknown(7) SCSICtrlCardType ::= TEXTUAL-CONVENTION STATUS current DESCRIPTION "SCSI Card type." SYNTAX INTEGER { none(0), differentialNoTermination(1), differentialTerminated(2), singleEndedNoTermination(3), singleEndedTerminated(4), unknown(5), lowVoltageSingleEnded(6), lowVoltageDifferential(7), lowVoltageMultiFunction(8), highVoltageDifferential(9) FCPortLoopIdMode ::= TEXTUAL-CONVENTION...
  • Page 97 "Cleaning Status." SYNTAX INTEGER { required( 1 ), notRequired( 2 ), immediate( 3 ) InterfaceType ::= TEXTUAL-CONVENTION STATUS current DESCRIPTION "Types of interfaces." SYNTAX INTEGER { scsi( 1 ), fibreChannel( 2 ), sas (3), iscsi(4) Scalar i500 Basic SNMP Reference Guide...
  • Page 98 IEDoorStatus ::= TEXTUAL-CONVENTION STATUS current DESCRIPTION "Import Export Station Door Status." SYNTAX INTEGER { opened( 1 ), closedAndLocked( 2 ), closedAndUnLocked( 3 ) RASSubSystemStatus ::= TEXTUAL-CONVENTION STATUS current DESCRIPTION "RAS status" SYNTAX INTEGER { good( 1 ), failed( 2 ), degraded( 3 ), warning( 4 ), informational( 5 ),...
  • Page 99 STATUS current DESCRIPTION "Different port speeds in Gibabits per second." SYNTAX INTEGER { auto( 1 ), threeGbps( 2 ), sixGbps( 3 ) -- Tape Library parameters libraryIpAddress OBJECT-TYPE SYNTAX MAX-ACCESS STATUS Scalar i500 Basic SNMP Reference Guide DisplayString read-only current...
  • Page 100 DESCRIPTION library has only an IPV4 address, or both an IPV4 and an IPV6 address, the the IP address is displayed in IPV4 format (xxx.xxx.xxx.xxx). the library only has an IPV6 address, then it will report an IPV6 address." ::= { tapeLibrarySystem 1 } librarySNMPAgentDescription OBJECT-TYPE SYNTAX MAX-ACCESS...
  • Page 101 ::= { tapeLibrarySystem 9 } libraryProductName OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { tapeLibrarySystem 10 } libraryFirmwareVersion OBJECT-TYPE SYNTAX MAX-ACCESS Scalar i500 Basic SNMP Reference Guide DisplayString read-only current "Description of Library." DisplayString read-only current "Model of the Library." RASSubSystemStatus...
  • Page 102 STATUS DESCRIPTION ::= { tapeLibrarySystem 11 } physicalDrive OBJECT IDENTIFIER ::= { tapeLibraryMIB 11 } overallPhDriveReadinessStatus OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { physicalDrive 1 } physicalDriveTable OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { physicalDrive 3 } physicalDriveEntry OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION...
  • Page 103 Integer32, phDriveLoads Integer32, phDrivePhysicalSerialNumber DisplayString phDriveIndex OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { physicalDriveEntry 1 } phDriveSerialNumber OBJECT-TYPE SYNTAX MAX-ACCESS Scalar i500 Basic SNMP Reference Guide Integer32 (1..1000) not-accessible current "Table entry index value. Index of this Drive" DisplayString read-only...
  • Page 104 STATUS DESCRIPTION ::= { physicalDriveEntry 2 } phDriveModel OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { physicalDriveEntry 3 } phDriveVendor OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { physicalDriveEntry 4 } phDriveType OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { physicalDriveEntry 5 } phDriveLocation OBJECT-TYPE SYNTAX MAX-ACCESS...
  • Page 105 OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { physicalDriveEntry 11 } phDriveNeedsCleaning OBJECT-TYPE Scalar i500 Basic SNMP Reference Guide current "Device firmware level as would be reported in a SCSI Inquiry command." DisplayString read-only current "Name of the logical libary (partition)
  • Page 106 SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { physicalDriveEntry 12 } phDriveInterfaceType OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { physicalDriveEntry 13 } phDriveScsiLun OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { physicalDriveEntry 14 } phDriveScsiId OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { physicalDriveEntry 15 } phDriveLoads OBJECT-TYPE SYNTAX MAX-ACCESS...
  • Page 107 OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { rasSubSystem 4 } roboticsStatus OBJECT-TYPE SYNTAX MAX-ACCESS STATUS Scalar i500 Basic SNMP Reference Guide current "Physical Drive serial number." RASSubSystemStatus read-only current "Indicates overall power supply Status" RASSubSystemStatus read-only current "Indicates overall cooling fans Status."...
  • Page 108 DESCRIPTION ::= { rasSubSystem 5 } mediaStatus OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { rasSubSystem 6 } driveStatus OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { rasSubSystem 7 } operatorActionRequest OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { rasSubSystem 8 } logicalLibrary OBJECT IDENTIFIER ::= { tapeLibraryMIB 13 } numLogicalLibraries OBJECT-TYPE SYNTAX MAX-ACCESS...
  • Page 109 Integer32, logicalLibraryMediaDomain DisplayString, logicalLibrarySupportedMediaTypes DisplayString, logicalLibraryState OnlineState, logicalLibraryNumSlots Integer32, logicalLibraryNumIE Integer32, logicalLibraryNumTapeDrives Integer32, logicalLibraryStorageElemAddr Integer32, logicalLibraryIEElemAddr Scalar i500 Basic SNMP Reference Guide current "Logical Library Table." LogicalLibraryEntry not-accessible current "Please replace this text with your description." { logicalLibraryIndex }...
  • Page 110 Integer32, logicalLibraryTapeDriveElemAddr Integer32, logicalLibraryChangerDeviceAddr Integer32 logicalLibraryIndex OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { logicalLibraryEntry 1 } logicalLibraryName OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { logicalLibraryEntry 2 } logicalLibrarySerialNumber OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { logicalLibraryEntry 3 } logicalLibraryModel OBJECT-TYPE SYNTAX MAX-ACCESS STATUS...
  • Page 111 ::= { logicalLibraryEntry 8 } logicalLibraryNumSlots OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { logicalLibraryEntry 9 } logicalLibraryNumIE OBJECT-TYPE SYNTAX MAX-ACCESS Scalar i500 Basic SNMP Reference Guide read-only current DisplayString read-only current "Supported Media Domain." DisplayString read-only current "Supported Media Types."...
  • Page 112 ::= { logicalLibraryEntry 15 } current "Number of Import/Export Elements." Integer32 read-only current "Number of tape drives in the partition." Integer32 read-only current "First Storage Element Address of the partition." Integer32 read-only current Integer32 read-only current Integer32 read-only current "First Medium Transport Element Address."...
  • Page 113 MAX-ACCESS STATUS DESCRIPTION ::= { physicalLibrary 4 } numIESlots OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION Scalar i500 Basic SNMP Reference Guide OnlineState read-only current "Physical library's overall online status" LibraryDoorStatus read-only current "The status is 'open' if any door is open."...
  • Page 114 ::= { physicalLibrary 5 } numPhDrives OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { physicalLibrary 6 } robot OBJECT IDENTIFIER ::= { physicalLibrary 30 } robotState OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { robot 2 } libraryInterfaces OBJECT IDENTIFIER ::= { tapeLibraryMIB 15 } fcPortTable OBJECT-TYPE SYNTAX MAX-ACCESS...
  • Page 115 DisplayString, fcPortFrameSize Integer32, fcPortDriveSerialNumber DisplayString, fcPortLogicalLibrarySerialNumber DisplayString fcPortIndex OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { fcPortEntry 1 } fcPortType OBJECT-TYPE SYNTAX FCPortType MAX-ACCESS read-only STATUS current Scalar i500 Basic SNMP Reference Guide Integer32 (1..1000) not-accessible current "Table entry index value."...
  • Page 116 DESCRIPTION "Fibre Channel Port Type" ::= { fcPortEntry 2 } fcPortWWNodeName OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION Node Name." ::= { fcPortEntry 3 } fcPortWWPortName OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION fabric." ::= { fcPortEntry 4 } fcPortLoopId OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { fcPortEntry 5 } fcPortLoopIdMode OBJECT-TYPE...
  • Page 117 DESCRIPTION "Firmware revision number/identifier for this Fibre Channel Controller." ::= { fcPortEntry 10 } fcPortFrameSize OBJECT-TYPE SYNTAX Integer32 Scalar i500 Basic SNMP Reference Guide Integer32 read-only current "Port ID for fabric attached Fibre Channel drive, for other interface types." FCPortSpeed...
  • Page 118 MAX-ACCESS read-only STATUS current DESCRIPTION "Fibre Channel frame size." ::= { fcPortEntry 11 } fcPortDriveSerialNumber OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "Tape drive serial number." ::= { fcPortEntry 12 } fcPortLogicalLibrarySerialNumber OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "Tape drive logical library serial number."...
  • Page 119 STATUS DESCRIPTION ::= { scsiControllerEntry 1 } scsiControllerRasStatus SYNTAX RASSubSystemStatus MAX-ACCESS read-only STATUS current DESCRIPTION "Currently not applicable." ::= { scsiControllerEntry 2 } scsiControllerSpeed Scalar i500 Basic SNMP Reference Guide Integer32 (1..1000) not-accessible current "Table entry index value." OBJECT-TYPE OBJECT-TYPE...
  • Page 120 SYNTAX SCSICtrlSpeed MAX-ACCESS read-only STATUS current DESCRIPTION "SCSI Transaction speed." ::= { scsiControllerEntry 3 } scsiControllerRole SYNTAX INTEGER{ target(0) , initiator(1) } MAX-ACCESS read-only STATUS current DESCRIPTION "SCSI role of the drive (target or initiator)" ::= { scsiControllerEntry 4 } scsiControllerIoCard SYNTAX SCSICtrlCardType...
  • Page 121 "Serial Number of Tape Drive." ::= { scsiControllerEntry 10 } scsiControllerLogicalLibrarySN OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "Logical library serial number." ::= { scsiControllerEntry 11 } sasPortTable OBJECT-TYPE SYNTAX MAX-ACCESS STATUS Scalar i500 Basic SNMP Reference Guide SEQUENCE OF SasPortEntry not-accessible current...
  • Page 122 DESCRIPTION ::= { libraryInterfaces 3 } sasPortEntry OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION INDEX ::= { sasPortTable 1 } SasPortEntry ::= SEQUENCE { sasPortIndex Integer32, sasPortAddress DisplayString, sasPortRasStatus RASSubSystemStatus, sasPortNegotiatedSpeed SASPortSpeed, sasPortFWRev DisplayString, sasPortDriveSerialNumber DisplayString, sasPortLogicalLibrarySN DisplayString sasPortIndex OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { sasPortEntry 1 }...
  • Page 123 ::= { sasPortEntry 5 } sasPortDriveSerialNumber OBJECT-TYPE SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "Tape drive serial number." ::= { sasPortEntry 6 } sasPortLogicalLibrarySN OBJECT-TYPE Scalar i500 Basic SNMP Reference Guide current "8-byte value representing the World Wide Name for this drive" OBJECT-TYPE...
  • Page 124 SYNTAX DisplayString MAX-ACCESS read-only STATUS current DESCRIPTION "Logical library serial number." ::= { sasPortEntry 7 } -- start blade additions -- Reboot Image Agent and Reset Controllers Reset ::= INTEGER { run(0) , reset(1) , reboot(2) } -- Device types DeviceType ::= INTEGER{ directAccess(0), sequentialAccess(1), printer(2), processor(3), worm(4), cd(5), scanner(6), opticalMemory(7),...
  • Page 125 STATUS DESCRIPTION ::= { bladeInterfaces 1 } bladeEntry OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION INDEX ::= { bladeTable 1 } Scalar i500 Basic SNMP Reference Guide pointToPointOnly(1), loopPreferred(2), pointToPointPreferred(3) } SEQUENCE OF BladeEntry not-accessible current "Data Appliance Blade Table" BladeEntry not-accessible current "Data Appliance Blade Entry"...
  • Page 126 BladeEntry ::= SEQUENCE { bladeIndexINTEGER, bladeLocation DisplayString, bladeIP DisplayString, bladeWWNodeName OCTET STRING, bladeHealthCheckValueGauge, bladeHealthCheckInterval Gauge, bladeHealthCheckLevelGauge, bladeFWRevDisplayString, bladeSerialNumberDisplayString, bladeEVPSEnabledINTEGER, bladeMaxHostLunINTEGER, bladeState blHPFLinkDownThreshold blHPFErrorRecoveryMode blHPFLinkDownRecoveryMode -- Begin definitions bladeIndex OBJECT-TYPE SYNTAX INTEGER ACCESS read-only STATUS mandatory DESCRIPTION "Blade index" ::= { bladeEntry 1 } bladeLocation OBJECT-TYPE SYNTAX DisplayString...
  • Page 127 SYNTAX Gauge{ none(0), system(1) , interface(2) , simpleDevice(3), deviceReady(4) } ACCESS read-only STATUS mandatory DESCRIPTION "Scrutiny level of health check function." ::= { bladeEntry 6 } bladeHealthCheckInterval OBJECT-TYPE SYNTAX Gauge ACCESS read-only STATUS mandatory Scalar i500 Basic SNMP Reference Guide...
  • Page 128 DESCRIPTION "Health Check interval in minutes." ::= { bladeEntry 7 } bladeFWRev OBJECT-TYPE SYNTAX DisplayString (SIZE (0..64)) ACCESS read-only STATUS mandatory DESCRIPTION "Blade Firmware Revision information." ::= { bladeEntry 8 } bladeSerialNumber OBJECT-TYPE SYNTAX DisplayString (SIZE (0..64)) ACCESS read-only STATUS mandatory DESCRIPTION "Blade Serial Number."...
  • Page 129 ::= { bladeEntry 15 } -- One Level down -- Blade Device Info blDevTable OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION ::= { bladeInterfaces 2 } Scalar i500 Basic SNMP Reference Guide OBJECT-TYPE OBJECT-TYPE OBJECT-TYPE SEQUENCE OF BlDevEntry not-accessible current "Data Appliance Blade Device Table"...
  • Page 130 blDevEntry OBJECT-TYPE SYNTAX MAX-ACCESS STATUS DESCRIPTION INDEX ::= { blDevTable 1 } BlDevEntry ::= SEQUENCE { blDevIndexINTEGER, blDevUIDDisplayString, blDevTypeDeviceType, blDevVendorDisplayString, blDevProductDisplayString, blDevSerialDisplayString, blDevInterfaceTypeInterfaceType, blDevLunINTEGER, blDevCtlrIndexINTEGER, blDevFWRevDisplayString, blDevTargetLunINTEGER blDevIndex OBJECT-TYPE SYNTAX INTEGER ACCESS read-only STATUS mandatory DESCRIPTION "MIB table index" ::= { blDevEntry 1 } blDevUID OBJECT-TYPE SYNTAX...
  • Page 131 ::= { blDevEntry 7 } blDevLun OBJECT-TYPE SYNTAX INTEGER ACCESS read-only STATUS mandatory DESCRIPTION "SCSI Logical Unit Number of the device." ::= { blDevEntry 8 } blDevCtlrIndex OBJECT-TYPE SYNTAX INTEGER ACCESS read-only STATUS mandatory DESCRIPTION Scalar i500 Basic SNMP Reference Guide...
  • Page 132 "Index of this device's controller in the Controllers MIB table and type-specific controller tables" ::= { blDevEntry 9 } blDevFWRev OBJECT-TYPE SYNTAX DisplayString( SIZE(0..32)) ACCESS read-only STATUS mandatory DESCRIPTION "Device firmware revision number/identifier" ::= { blDevEntry 10 } blDevTargetLun OBJECT-TYPE SYNTAX INTEGER ACCESS read-only STATUS mandatory...
  • Page 133 Bit 10 => Is access DISALLOWED to Fibre Channel 1 ? Bit 11 => Is access DISALLOWED to Fibre Channel 2 ? Bit 12 => Is access DISALLOWED to Fibre Channel 3 ? Scalar i500 Basic SNMP Reference Guide -* Fibre Channel *-...
  • Page 134 Bit 13 => Is access DISALLOWED to Fibre Channel 4 ? Bit 14 => Is access DISALLOWED to Fibre Channel 5 ? Bit 15 => Is access DISALLOWED to Fibre Channel 6 ? Bit 16 => Is access DISALLOWED to SSA channel 1 ? Bit 17 =>...
  • Page 135 SYNTAX FCPortLoopIdMode ACCESS read-only STATUS mandatory DESCRIPTION "Fibre Channel loop ID mode (soft or hard)" ::= { blFcCtlrEntry 5 } blFcCtlrPortMode OBJECT-TYPE SYNTAX FibrePortMode ACCESS read-only STATUS mandatory DESCRIPTION "Fibre Channel port mode." Scalar i500 Basic SNMP Reference Guide OBJECT-TYPE...
  • Page 136 ::= { blFcCtlrEntry 6 } blFcCtlrConnectionOptions OBJECT-TYPE SYNTAX FibreConnOptions ACCESS read-only STATUS mandatory DESCRIPTION "Connection options for ISP2200 FC chip. Values 4 - 8 are reserved." ::= { blFcCtlrEntry 7 } -- EVPS/Host mapping/management blHostTable OBJECT-TYPE SYNTAX SEQUENCE OF BlHostEntry ACCESS not-accessible STATUS mandatory DESCRIPTION...
  • Page 137 DisplayString( SIZE( 0 .. 32 ) ) ACCESS read-only STATUS mandatory DESCRIPTION "The ID of the host port " ::= { blHostEntry 5 } blHostITLData OBJECT-TYPE SYNTAX OCTET STRING ( SIZE( 256 ) ) ACCESS read-only STATUS mandatory Scalar i500 Basic SNMP Reference Guide...
  • Page 138 DESCRIPTION "Initiator-Target-Logical Unit nexus (ITL) Access Control data for this host. with 1 byte of data per LUN. " ::= { blHostEntry 6 } blHostLunMap OBJECT-TYPE SYNTAX OCTET STRING ( SIZE( 512 ACCESS read-only STATUS mandatory DESCRIPTION "EVPS Map data. with 2 bytes of data for each lun"...
  • Page 139 STATUS mandatory DESCRIPTION "The physical port that is active on this virtual port" ::= { blHPFMapEntry 4 } Scalar i500 Basic SNMP Reference Guide -- Comma seperated list of standby Ports INTEGER -- The port index of the active port...
  • Page 140 blHPFPhysicalTable OBJECT-TYPE SYNTAX SEQUENCE OF BlHPFPhysicalEntry ACCESS not-accessible STATUS mandatory DESCRIPTION "" ::= { bladeInterfaces 7 } blHPFPhysicalEntry OBJECT-TYPE SYNTAX BlHPFPhysicalEntry ACCESS not-accessible STATUS mandatory DESCRIPTION " SNMP table for FC Host Port Failover Port Settings " INDEX { bladeIndex, blHPFPhysicalPort } ::= { blHPFPhysicalTable 1 } BlHPFPhysicalEntry ::= SEQUENCE { blHPFPhysicalPort INTEGER,...
  • Page 141 1 = true, 2 = false" ::= { blHPFPhysicalEntry 4 } -- end blade additions startupSequenceCompleted NOTIFICATION-TYPE OBJECTS librarySerialNumber, libraryGlobalStatus STATUS DESCRIPTION Scalar i500 Basic SNMP Reference Guide OBJECT-TYPE current "Notify that the library has completed its boot sequence." --#TYPE "Startup Sequence Completed"...
  • Page 142 sequence and is at status %d." ::= { tapeLibraryMIBNotifications 101 } shutdownSequenceInitiated NOTIFICATION-TYPE OBJECTS librarySerialNumber, libraryGlobalStatus STATUS DESCRIPTION sequence and is at status %d." ::= { tapeLibraryMIBNotifications 102 } phLibrayStateChange NOTIFICATION-TYPE OBJECTS librarySerialNumber, physicalLibraryState STATUS DESCRIPTION changed." --#TYPE "Change in Online state of the Physical Library" state and is at state %d."...
  • Page 143 DESCRIPTION ready." ::= { tapeLibraryMIBNotifications 106 } roboticsNotReady NOTIFICATION-TYPE Scalar i500 Basic SNMP Reference Guide current "Notify that the status of the module door changed." --#TYPE "Change in main Chassis door status" --#SUMMARY "The Main chassis door of the library %s...
  • Page 144 OBJECTS librarySerialNumber STATUS DESCRIPTION not ready." ::= { tapeLibraryMIBNotifications 107 } logicalLibraryStateChange NOTIFICATION-TYPE OBJECTS logicalLibraryName, librarySerialNumber, logicalLibraryState STATUS DESCRIPTION changed the online state and online state is at %d." ::= { tapeLibraryMIBNotifications 108 } connectivityStatusChange NOTIFICATION-TYPE OBJECTS librarySerialNumber, connectivityStatus STATUS DESCRIPTION --#TYPE "RAS status of the Connectivy SubSystem Changed"...
  • Page 145 NOTIFICATION-TYPE OBJECTS librarySerialNumber, phDriveRasStatus STATUS DESCRIPTION Scalar i500 Basic SNMP Reference Guide current "Notify when control health status changed." --#TYPE "RAS status of the Control SubSystem Changed" --#SUMMARY "The Control Subsystem of the library %s --#ARGUMENTS {0,1} --#SEVERITY INFORMATIONAL current "Notify on cooling health status change."...
  • Page 146 has changed the RAS status and the RAS status is at %d." ::= { tapeLibraryMIBNotifications 112 } mediaStatusChange NOTIFICATION-TYPE OBJECTS librarySerialNumber, mediaStatus STATUS DESCRIPTION has changed the RAS status and the RAS status is at %d." ::= { tapeLibraryMIBNotifications 113 } powerStatusChange NOTIFICATION-TYPE OBJECTS librarySerialNumber,...
  • Page 147 STATUS DESCRIPTION library %s has changed the online state and online state is at %d." Scalar i500 Basic SNMP Reference Guide current "Notify robotics health status change." --#TYPE "RAS status of the Robotics SubSystem Changed" --#SUMMARY "The Robotics Subsystem of the library...
  • Page 148 ::= { tapeLibraryMIBNotifications 117 } -- conformance information tapeLibraryMIBConformance OBJECT IDENTIFIER ::= { tapeLibraryMIB 4 } tapeLibraryMIBCompliances OBJECT IDENTIFIER ::= { tapeLibraryMIBConformance 1 } tapeLibraryMIBGroups -- compliance statements tapeLibraryMIBCompliance MODULE-COMPLIANCE STATUS current DESCRIPTION "The compliance statement for entities which implement Tape Library MIB"...
  • Page 149 Scalar i500 Basic SNMP Reference Guide...
  • Page 150 roboticsStatus, mediaStatus, driveStatus, operatorActionRequest, numLogicalLibraries, physicalLibraryState, aggregatedMainDoorStatus, aggregatedIEDoorStatus, numStorageSlots, numIESlots, robotState, fcPortType, fcPortWWNodeName, fcPortWWPortName, fcPortLoopId, fcPortLoopIdMode, fcPortId, fcPortNegotiatedSpeed, fcPortRasStatus, fcPortFWRev, fcPortFrameSize, fcPortDriveSerialNumber, fcPortLogicalLibrarySerialNumber, scsiControllerRasStatus, scsiControllerSpeed, scsiControllerRole, scsiControllerIoCard, scsiControllerMaxIds, scsiControllerMaxLuns, scsiControllerMaxWidth, scsiControllerFWRev, scsiControllerDriveSerialNumber, scsiControllerLogicalLibrarySN, MIBs Implemented...
  • Page 151 -- start blade additions -- blade top-level bladeIndex, bladeLocation, bladeIP, bladeWWNodeName, bladeHealthCheckValue, bladeHealthCheckInterval, bladeHealthCheckLevel, bladeFWRev, bladeSerialNumber, bladeEVPSEnabled, bladeMaxHostLun, bladeState, blHPFLinkDownThreshold, blHPFErrorRecoveryMode, blHPFLinkDownRecoveryMode, -- devices /blade level blDevIndex, blDevUID, blDevType, blDevVendor, blDevProduct, blDevSerial, blDevInterfaceType, blDevLun, blDevCtlrIndex, blDevFWRev, blDevTargetLun, Scalar i500 Basic SNMP Reference Guide...
  • Page 152 -- controllers /blade level blCtlrIndex, blCtlrType, blCtlrChannelMask, -- FC controllers /blade/controllers level blFcCtlrStatus, blFcCtlrMaxSpeed, blFcCtlrWWPortName, blFcCtlrLoopID, blFcCtlrLoopIDMode , blFcCtlrPortMode, blFcCtlrConnectionOptions, -- EVPS blHostIndex, blHostWWName, blHostName, blHostType, blHostPortID, blHostITLData, blHostLunMap, -- HPF blHPFMapVirtualPort, blHPFMapPrimaryPort, blHPFMapStandbyList, blHPFMapActivePort, blHPFPhysicalPort, blHPFPhysicalPortFailureType, blHPFPhysicalPortCurrentState, blHPFPhysicalPortIntervention -- end blade additions STATUS current MIBs Implemented...
  • Page 153 STATUS current DESCRIPTION "A collection of objects providing Tape Library Management capability." ::= { tapeLibraryMIBGroups 2 } Scalar i500 Basic SNMP Reference Guide...
  • Page 154 MIBs Implemented...
