Avaya DEFINITY Server CSI Maintenance Manual page 132

Maintenance for CSI systems
display circuit-packs 2
Cabinet: 2
Cabinet Layout: single-carrier-stack
Slot Code Sfx
01: TN2305 ATM PNC EI
02:
03:
04:
05:
06:
07:
08:
09: TN767 E
10: TN754 B
'#' indicates circuit pack conflict.
Screen 21. Screen output for display circuit-packs 2
4. Enter display atm pnc portnetwork on the Avaya Definity Server CSI
SAT.
This screen shows the ATM addresses that have been administered for
each TN230X. Verify that each ATM address (the concatenation of the five
hexadecimal fields) is correct and match those administered in the A500.
See
Administered with hard coded PNNI routes
If the port networks are addressed using hard coded PNNI routes in the
A500, the screen looks like
display atm pnc 1
Location: 01B02
Name:
Address Format: ICD ATM
AFI: 47
ICD: 0005
HO-DSP: 80FFE1000000F2071B02
ESI: 000000000000
SEL: 00
Screen 22. Screen output for display atm pnc 1
132
Issue 5 October 2002
CIRCUIT PACKS
Name
DS1 INTERFACE
DIGITAL LINE
''A500 Administration'' on page 134
ATM PNC
Connection Number: 1
Carrier: A
Carrier Type: expansion-control
Slot Code Sfx Name
11: TN746 B ANALOG LINE
12:
13:
14:
15:
16:
17: TN754 C DIGITAL LINE
for more information.
Screen 22 (pnc 1) and Screen 23 (pnc 2).
555-233-119
