Chapter 5 Quality of Service Commands
S e n d c o m m e n t s t o n x 5 0 0 0 - d o c f e e d b a c k @ c i s c o . c o m

match dscp

To identify specific Differentiated Services code point (DSCP) values as a match criteria, use the match
dscp command. To remove specified DSCP values as a match criteria, use the no form of this command.
Syntax Description
not
dscp-list
Defaults None
Command Modes Class-map type qos configuration
Command History Release
4.1(3)N1(1)
Usage Guidelines The standard DSCP values are shown in
To specify a list of values, use one of the following options:
Table 1
af11
af12
af13
af21
af22
af23
af31
af32
af33
af41
af42
af43
cs1
OL-16599-01
match [not] dscp dscp-list
no match [not] dscp dscp-list
(Optional) Negates the specified match result.
Matches on the specified DSCP value or list of DSCP values. See
for a list of valid DSCP values.
Modification
This command was introduced.
Standard DSCP Values
List of DSCP Values
AF11 dscp (001010)—decimal value 10
AF12 dscp (001100)—decimal value 12
AF13 dscp (001110)—decimal value 14
AF21 dscp (010010)—decimal value 18
AF22 dscp (010100)—decimal value 20
AF23 dscp (010110)—decimal value 22
AF31 dscp (011010)—decimal value 26
AF40 dscp (011100)—decimal value 28
AF33 dscp (011110)—decimal value 30
AF41 dscp (100010)—decimal value 34
AF42 dscp (100100)—decimal value 36
AF43 dscp (100110)—decimal value 38
CS1 (precedence 1) dscp (001000)—decimal value 8
Table 1.
Cisco Nexus 5000 Series Command Reference
match dscp
Table 1
5-9
