Chapter 2 Ethernet Commands
S e n d c o m m e n t s t o n x 5 0 0 0 - d o c f e e d b a c k @ c i s c o . c o m

spanning-tree mst root

To designate the primary and secondary root and set the timer value for an instance, use the
spanning-tree mst root command. To return to the default settings, use the no form of this command.
Syntax Description
instance-id
primary
secondary
diameter dia
hello-time hello-time
Command Default None
Command Modes Configuration mode
Command History Release
4.0(0)N1(1a)
Usage Guidelines You can enter the instance-id argument as a single instance or a range of instances, for example,
0-3,5,7-9.
If you do not specify the hello-time argument, the argument is calculated from the network diameter.
You must first specify the diameter dia keyword and argument before you can specify the hello-time
hello-time keyword and argument.
Examples This example shows how to designate the primary root:
switch(config)# spanning-tree mst 0 root primary
This example shows how to set the priority and timer values for the bridge:
switch(config)# spanning-tree mst 0 root primary diameter 7 hello-time 2
OL-16599-01
spanning-tree mst instance-id root {primary | secondary} [diameter dia [hello-time hello-time]]
no spanning-tree mst instance-id root
Instance identification number; the range of valid values is from 0 to 4094.
Specifies the high priority (low value) that is high enough to make the bridge
root of the spanning-tree instance.
Specifies the switch as a secondary root, should the primary root fail.
(Optional) Specifies the timer values for the bridge that are based on the
network diameter.
(Optional) Specifies the duration between the generation of configuration
messages by the root switch. The range is from 1 to 10 seconds; the default
is 2 seconds.
Modification
This command was introduced.
Cisco Nexus 5000 Series Command Reference
spanning-tree mst root
2-67
