Canon iR C3200 Series Service Manual page 1056

Chapter 18
Address
Address
P001
(output)
P002
(output)
18-50
Bit Symbol Display
2 - DIPSW1 bit 3
3 - DIPSW1 bit 4
4 - DIPSW1 bit 5
5 - DIPSW1 bit 6
6 - DIPSW1 bit 7
7 - DIPSW1 bit 8
T-18-39
Bit Symbol Display
0 - -
1 - -
2 M8 Second feed motor A
phase output
3 M8 Second feed motor B
phase output
4 M4 Staple mover motor
B phase output
5 M4 Staple mover motor
A phase output
6 M3 Matching motor B
phase output
7 M3 Matching motor A
phase output
8 to 15 - -
0 M5 Tray UP/DOWN
motor PWM
1 M2 Paper delivery motor
PWM
2 M7 Rotary motor PWM
3 - -
4 - -
5 - -
Remarks
0: ON
0: ON
0: ON
0: ON
0: ON
0: ON
Remarks
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
