SLM-5650A Satellite Modem
NP Interface Telnet/SSH CLI Operation
9.2.3

Main Menu

The Main Menu serves as the CLI's primary navigation page. All selections made on this page
take the user to submenus listed in this table (operation features nested under each of these
submenus, in turn, are described in the chapter sections listed):
Submenu
Administration
Satellite Modem
Configuration
LAN
WAN
Route Table
OSPF
IGMP
Vipersat Configuration
Redundancy
Configuration
Operations and
Maintenance
Entry Function/Description
The Administration Menu provides a basic set of
A
standard admin functions to the NP Interface.
The Satellite Modem Configuration option displays
M nested menus that allow the user to configure and
monitor the satellite base modem.
The LAN menu allows the user to change the IP
N address and view the ARP (Address Resolution
Protocol) table.
The WAN menu allows the user to configure QoS
W
(Quality of Service) and DiffServ (Differentiated
Services).
The Route Table menu allows the user to configure the
R
Unicast/Multicast routing tables.
The OSPF Menu allows the user to configure Open
F
Shortest Path First routing parameters.
The IGMP Menu allows the user to configure Internet
I
Group Management Protocol parameters
The FAST-Feature-enabled Vipersat Configuration
menu allows the user to configure Vipersat
V
functionality. This menu selection is visible/available
only after the Vipersat option has been purchased.
The Redundancy Configuration Menu allows the user
E
to view the 1:1 IP redundancy status.
The Operations & Maintenance menu allows the user
to configure various options used to control and
O
maintain the system. This menu also provides
diagnostic tools for troubleshooting and statistics.
9–5
Revision 8
MN-SLM5650A
See...
Sect. 9.2.4 (9.2.4.1
through 9.2.4.8)
Sect. 9.2.5 (9.2.5.1
through 9.2.5.6)
Sect. 9.2.6 (9.2.6.1
through 9.2.6.3)
Sect. 9.2.7
Sect. 9.2.8
Sect. 9.2.9
Sect. 9.2.10
Sect. 9.2.11
Sect. 9.2.12
Sect. 9.2.13,
9.2.13.1
