SLM-5650A Satellite Modem
Front Panel Operation
To edit the Gigabit Ethernet Interface's Management IP Address and Range, first use the 
arrow keys to select the digit to edit, and then use the  arrow keys to edit the value of that
digit. Press [ENT] when done.
CONFIG: Remote
Proc
NP Card:
Use the  arrow keys to select AddrMode, Security, BPM, Traffic IP, or Mgmt IP , and
then press [ENT].
CONFIG: Remote
Proc

Use the  arrow keys to select the Address Mode as Local or Dual, and then press [ENT].
CONFIG: Remote
Proc

Use the  arrow keys to select the FAST-enabled Management Security level as Low or
High, and then press [ENT].
CONFIG: Remote
Proc

Use the  arrow keys to select the FAST-enabled BPM mode as On or Off, and then
press [ENT].
EthernetConfig

AddrMode:Dual
BPM:Off Traffic IP
EthernetConfig

AddrMode
When in Single Address Mode, select Traffic IP to edit the NP Module's
Ethernet IP Address and Range.
When in Dual Address Mode, select Mgmt IP to edit the NP Module's Ethernet
IP Address and Range.
EthernetConfig

Security
EthernetConfig

BPM
Option Card Addr

Security: Low
Mgmt IP
Option Card Addr

Option Card Addr

Option Card Addr

5–32
Revision 8
MN-SLM5650A
Network

(E)
Network

Network

Network

