SLM-5650A Satellite Modem
Base Modem HTTP Interface
7.3.3 Config Mdm (Modem Configuration) pages
The 'Config Mdm' pages are used to configure the Modulator, Demodulator, and installed
interfaces (e.g., EIA-530, HSSI, Balanced and Unbalanced G.703, Gigabit Ethernet, Network
Processor, and LVDS).
Select the Page 1, Page 2, Page 3, Spreading, or AUPC hyperlink to continue.
7.3.3.1 Config Mdm | Page 1
Use this page to configure modem configuration parameters including Modem Operating Mode;
Transmit/Receive; Tx Power Level; and DoubleTalk Carrier-in-Carrier (CnC).
Click [Submit] as needed in each section to save any changes.
Figure 7-6. Config Mdm | Modem Config (Page 1)
7–10
Revision 8
MN-SLM5650A
