SLM-5650A Satellite Modem
Network Processor (NP) Interface

8.2.1 Connector Pinout

The LAN interface is comprised of four IEEE 802.3ab 10/100/1000 BaseT copper interfaces via
four female RJ-45 connectors wired as shown in Table 8-1.

Table 8-1. LAN Interface Connector Pinout (Typical)

8.3

Interface Specifications

8.3.1 Physical Description

Dimensions
Connectors
Indicators

8.3.2 General Specifications

Data Framing
Data Framing Format (WAN)
Electrical Properties
Max Ethernet Frame
Packet Types
Signal Types
Voltage Level
Packet Latency
Cable Length, Maximum
Hot Pluggable
Pin # Description
1 BI_DA+
2 BI_DA-
3 BI_DB+
4 BI_DC+
5 BI_DC-
6 BI_DB-
7 BI_DD+
8 BI_DD-
4.5 W x 6.8 D x .85 H inches (11.43 W x 17.27 D x 2.16H cm)
SLM-5650A connection: (1) 96-pin DIN receptacle
Console interface for board bring-up and factory use only:
(1) RJ-11 connector
LAN interface: (4) RJ-45 female connectors, 100Ω
Link Status and Activity Light-Emitting Diodes (LEDs)
10/100/1000 BaseT Interface: RFC-894 "Ethernet"
CEFD proprietary
Per IEEE 802.3ab
1636 Bytes (Bridge mode)
1541 Bytes (Router mode)
Burst, distributed, or IPV4
Serial data
Per IEEE- 802.3ab
50 ms maximum
100 meters CAT 5 cable, patch cords and connecting hardware, per ISO/IEC
11801:1995 and ANSI/EIA/TIA-568-A (1995)
Card – No
Cable – Yes
8–3
Direction
Bidirectional
Revision 8
MN-SLM5650A
