SLM-5650A Satellite Modem
Appendix C
Command
Parameter (Instruction
Type Code and
Qualifier)
Rx Demod RSW= 8 bytes
Acquisition
Sweep Range
Live Rx Faults N/A 8 bytes
Arguments for
Command or
Response to
Query
Command or Query.
Rx acquisition sweep range of demodulator, in kHz, ranging from 0 to 60 kHz.
Example: RSW=0060.000 (selects 60 kHz)
Query only.
Live Rx Faults are returned as a 32 bit Hexadecimal value. Bit values are defined as
follows:
80000000 = Demodulator IF not locked
40000000 = Demodulator Data Decoder not locked
20000000 = Demodulator RF Synthesizer not locked
10000000 = Demodulator No IQ Activity
08000000 = Interface De-Multiplexers not locked
04000000 = Interface Buffer Fault
02000000 = Interface Buffer about to slip
01000000 = Interface Buffer has overflowed
00800000 = Interface Buffer has underflowed
00400000 = Interface Buffer Clock PLL not locked
00200000 = Interface Buffer Clock Reference Activity
00100000 = Interface Data/AIS
00080000 = Eb/No Threshold exceeded
00040000 = Composite Power > 40 dBc
00020000 = Composite Power > 20 dBm
00010000 = BERT Sync Loss
Example: RXF=00000000 indicates No Rx Faults
Description of Arguments
C–20
Revision 8
MN-SLM5650A
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
RSW= RSW? RSW=xxxx.xxx
RSW? (see Description
RSW* of Arguments)
RSW#
N/A RXF? RXF=xxxxxxxx
(see Description
of Arguments)
