SLM-5650A Satellite Modem
Introduction

FAST Accessible Options

SLM-5650A hardware options can be ordered and installed either at the factory or in the field. In
the field, the operator can select options that can be easily activated, depending on the current
hardware configuration of the unit. The unique FAST Access Code that is purchased from
Comtech EF Data enables configuration of the available hardware.
The following table shows the FAST-accessible hardware and FAST options available for the
SLM-5650A.
Option
Extended Temperature Range -32° to 50° C
Gigabit Ethernet Interface (Plug-in Card)
G.703 Interface (Plug-in Card)
Low-Density Parity Check (LDPC) FEC Option (Installed Card and FAST)
LVDS Interface (Plug-in Card)
Network Processor Interface Module (Plug-in Card)
TRANSEC Module (Installed Card and FAST)
Extended Temperature Range -32° to 50° C
Modem Data Rate: 2.5 Mbps, 5 Mbps, 10 Mbps, 20 Mbps, 52 Mbps, <155 Mbps.
Adv FEC Data Rate: 2.5 Mbps, 5 Mbps, 10 Mbps, 20 Mbps, 52 Mbps, <155 Mbps.
Turbo FEC Option
Asymmetrical Rx Data Rate: 5 Mbps, 10 Mbps, 20 Mbps, 52 Mbps, <155 Mbps.
Demodulator Only
8-PSK modulation
8QAM modulation
16-QAM modulation
16APSK/32APSK modulation
AUPC (Automatic Uplink Power Control) Overhead
ASYNC ESC
Carrier-In-Carrier
Network Processor Antenna Handover
Network Processor BPM (Bridge Point-to-Multipoint) Mode
Network Processor Management Security
Network Processor QoS
Network Processor Vipersat
Reed-Solomon Coding
Sequential Encode/Decoder
Spectrum Spreading (DSSS)
TRANSEC Data Rate: 2.5 Mbps, 5 Mbps, 10 Mbps, 20 Mbps, 52 Mbps, <155 Mbps.
Vipersat Data Rate: 2.5 Mbps, 5 Mbps, 10 Mbps, 20 Mbps, 52 Mbps, <155 Mbps.
(future)
1–10
Revision 8
MN-SLM5650AMN-SLM5650A
How Enabled
HARDWARE
FAST
