SLM-5650A Satellite Modem
Ethernet-Based Management
Type the SNMP Community String into the user-supplied MIB Browser or Network Node
Management software.
The user defines three Community Strings for SNMP access:
• Read Community
• Write Community default = private
• Trap Community
Note: Maximum number of characters for community strings shall not exceed 20. All printable
ASCII characters, except '\' and '~' are allowed. No trailing spaces for community strings.
For proper SNMP operation, the SLM-5650A MIB files must be used with the
associated version of the SLM-5650A base modem M&C. Please refer to the
SLM-5650A SW Release Notes for information on the required FW/SW compatibility.

6.4.3 SNMP Traps

These include unit faults, TX faults, and RX faults. A trap is sent both when a fault occurs and is
cleared.
The "Traps" file only needs to be compiled if SNMPv1 traps are to be used. SNMPv3 does not
currently support traps. Which style of traps the modem sends can be configured by the user
using the slm5650SNMPTrapVersion OID.
The modem supports the following MIB2 SNMPv1traps / SNMPv2 notifications:
MIB2 SNMPv1 trap: Authentication Failure
MIB2 SNMPv2 notifications: Authentication Failure
The modem supports the following Alarms and Faults SNMPv1 traps / SNMPv2 notifications:
slm5650TxTrafficAlarmV1
slm5650UnitAlarmV1
slm5650RedundancyStateV1
slm5650RedundancyStateV1
slm5650UnitAlarmV2
slm5650TxTrafficAlarmV2
slm5650RxTrafficAlarmV2
slm5650RedundancyStateV2
default = public
default = comtech
Alarms and Faults SNMPv1 traps
6247472
6247471
6247473
6247474
Alarms and Faults SNMPv2 notification
1.3.6.1.4.1.6247.47.2.1.1
1.3.6.1.4.1.6247.47.2.1.2
1.3.6.1.4.1.6247.47.2.1.3
1.3.6.1.4.1.6247.47.2.1.4
6–6
5
1.3.6.1.6.3.1.1.5.5
Revision 8
MN-SLM5650A
