SLM-5650A Satellite Modem
Front Panel Operation
Setting
Nominal:
Min:
Max:
CONFIG: AUPC
Target Settings:
First, use thearrow keys to select Eb/No or RateOfChange, and then press [ENT].
Then, for either selection, use thearrow keys to first select the digit to edit, and then use
the  arrow keys to edit the value of that digit. Press [ENT] once again when done.
Setting
Eb/No
RateOfChange
CONFIG: AUPC
Carrier Loss: Local:
First, use thearrow keys to select Local or Remote, and then press [ENT]. Then, for
either selection, use the  arrow keys to select HOLD, NOMINAL, or MAXIMUM.
Option
Local
Remote
CONFIG: AUPC
Remote AUPC: Enable: Off BasebandL: Off
Tx Pattern: Off BER: Loss
First, use the arrow keys to select Enable, BasebandL, Tx Pattern, or BER, and then press
[ENT]. Then, typical for all selections, use the  arrow keys to select operation as On or Off.
Option
Enable
Valid Operational Range
Nominal Output Power: : -40 to +10 dB.
Minimum Output Power: -40 to +10 dB.
Maximum Output Power: -40 to +10 dB.
Local Target Settings
 
Eb/No: 0.60 dB
RateOfChange: 1.0 dB/Minute
Valid Operational Range
To set the Target Eb/No for AUPC: 3.2–16.0 dB.
To set the maximum tracking rate: 0.5–6.0 dB per minute (in 0.5 dB increments)
Local Carrier Loss Action
 
Remote: HOLD
Function
Sets the action of the local modem when it loses carrier detect.
Sets the action of the local modem when the remote modem loses carrier detect.
Remote

Function
View or modify the status of the remote modem's AUPC Enable.
5–24
(E)
HOLD
(E)
(E)
Revision 8
MN-SLM5650A
