SLM-5650A Satellite Modem
Front Panel Operation
Option
Clear-All
Config
5.2.3.5 CONFIG: Transec
TRANSEC: State: Encrypted
Module IP Address
Use the arrow keys to select State, Module IP Address, or Gateway, and then press [ENT].
Option
State
Module IP
Address
Gateway
5.2.3.6 CONFIG: AntHndOvr
AntHndOvr: Mode: Off
Use the arrow keys to select Mode, State, PwrOffset, or Delay, and then press [ENT].
Setting
Mode
State
PwrOffset
Delay
5.2.3.7 CONFIG: Ref
Reference: Internal Ext-1Mhz
Use the arrow keys to select Internal, Ext-1Mhz, Ext-5Mhz or Ext-1Mhz, and then press
[ENT].
Settings
Use the arrow keys to select No or Yes to clear all stored AUPC statistics, and then
press [ENT].
Use the  arrow keys to set the interval that the statistics are stored, and then press
[ENT]. Valid selections are 10 minutes through 90 minutes (in 10-minute increments), or
Disabled.
Settings
Select Encrypted or Bypass.
Set the TRANSEC Module's Management IP Address and subnet mask length.
Set the TRANSEC Module's IP Gateway.
PwrOffset: +01.2 Delay: 040ms (E)
Function
Select the Antenna Handover Mode as Off, Man, or Auto.
Select the current modem state as ONLINE or OFFLINE.
Select the offset that is added to the Tx power level to compensate for system loss.
Select the size of the buffer used during Handover events.
Ext-5Mhz Ext-10Mhz
Gateway (E)
State: ONLINE
(E)
5–26
Revision 8
MN-SLM5650A
