SLM-5650A Satellite Modem
Base Modem HTTP Interface
Stats Selection / Feature Page
FPGA
LAN Port 1
(NP Interface Traffic
Port marked as 1)
LAN Port 2
(NP Interface Traffic
Port marked as 2)
LAN Port 3
(NP Interface Traffic
Port marked as 3)
(Ethernet)
LAN Port 4
(NP Interface Traffic
Port marked as 4)
WAN
(Traffic port connected
to satellite interface)
Management
(Management port for
accessing M&C)

Table 7-1. Summary of Attributes for Router Stats Pages

Attribute
FPGA Link Errors
FPGA Overrun Errors
FPGA Rx Packet
count
FPGA Overflow Errors
FPGA TX Packet
counts
Good Octets (in)
Bad Octets (in)
Unicast (in)
Broadcast (in)
Multicast (in)
Pause (in)
Undersize (In)
Fragments (in)
Oversized (in)
Jabber (in)
Rx Err (in)
FCS (in)
Octets (Out)
Unicast (Out)
Broadcast (out)
Multicast (Out)
The count of received frames that did not match the
proprietary HDLC address, bad HDLC CRC, bad
alignment, and under run.
Count of received frames that exceeded max frame
length of 2K bytes in length.
Total number of received frames.
Count of received frames that overflowed the HDLC
buffer.
Total Number of transmitted frames.
Total good Ethernet frames received, that is frames
that are not bad frames.
Total bad Ethernet frames received.
The number of good frames received that have a
Unicast destination GMAC address
The number of good frames received that have a
broadcast destination GMAC address.
The number of good frames that have multicast
destination GMAC address.
Note: this address not included 802.3 Flow Control
messages counted in Pause (In) or does it included
Broadcast frames counted in Broadcast (in).
The number of good Flow Control frames received.
Total frames received with length of less than 64
octets but with valid FCS.
Total frames received with length of less than 64
octets but with invalid FCS.
Total frames received with length of more than
Maxsize (1643 in bridge mode and 1522 in all other
modes) but with valid FCS.
Total frames received with length of more than
Maxsize (1643 in bridge mode and 1522 in all other
modes) but with invalid FCS.
Total frames received with RxErr signal from PHY.
Total Frames received with a CRC error not counted
in Fragments (In), Jabber (In) or RxErr (In).
Total Ethernet frames sent from this GMAC
The number of frames sent that have a Unicast
destination GMAC address.
The number of frames sent that have a Broadcast
destination GMAC address.
The number of frames sent that have a Multicast
destination GMAC address.
7–20
Revision 8
MN-SLM5650A
Description
