Comtech EF Data SLM-5650A Installation And Operation Manual page 380

SLM-5650A Satellite Modem
Appendix C
Command
Parameter (Instruction
Type Code and
Qualifier)
Retrieve next 5 N/A 105 bytes
unread Stored
Statistics
Serial Number N/A 9 bytes
Statistics SSI= 1 byte
Sample Interval
Software N/A 43 bytes
Revision
RTC Time TIM= 6 bytes
Temperature N/A 3 bytes
Arguments for
Command or
Response to
Query
Query only.
Unit returns the oldest 5 Stored Statistics which have not yet been read over the
remote control.
Reply format: {CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-
body, where Sub-body= AA.ABB.Bddmmyyhhmmss,
AA.A = Minimum Eb/No during sample period. "Loss" is displayed if carrier was
lost during the sample period.
BB.B = Average Eb/No during sample period. "Loss" is displayed if carrier was
lost during the entire sample period.
If there are less than 5 events to be retrieved, the remaining positions are padded
with zeros.
If there are no new events, the response is RNS*.
Query only.
Used to query the unit 9-digit serial number. Unit returns its S/N in the form
xxxxxxxxx.
Example: SNO=176500143
Command or Query.
Used to set the sample interval for the Statistics Logging Function.
SSI=x, where x = 0 to 9 in 10 minute steps.
Note: Setting this parameter to 0 disables the statistics logging function.
Example: SSI=3 sets the logging inverval to 30 minutes
Query only.
Unit returns the value of the internal software revision installed in the unit, in the
form:
Boot:xx.yy.zz Bulk1:xx.yy.zz Bulk2:xx.yy.zz
Example: SWR=Boot:01.01.01 Bulk1:01.01.01 Bulk2:01.01.01
Command or Query.
A time in the form hhmmss, indicating the time from midnight, where:
hh = hours (00 to 23)
mm = minutes (00 to 59)
ss = seconds (00 to 59)
Example: TIM=231259 (23 hours:12 minutes:59 seconds)
Query only.
Unit returns the value of the internal temperature, in the form of xxx (degrees C).
Example: TMP=+26
Description of Arguments
C–28
Revision 8
MN-SLM5650A
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
N/A RNS? RNS={CR}AA.AB
B.Bddmmyyhhmm
ss{CR}AA.ABB.Bd
dmmyyhhmmss{C
R}AA.ABB.Bddm
myyhhmmss{CR}
AA.ABB.Bddmmy
yhhmmss{CR}AA.
ABB.Bddmmyyhh
mmss
(see Description
for Arguments)
N/A SNO? SNO=xxxxxxxxx
(see Description
of Arguments)
SSI= SSI? SSI=x
SSI? (see Description
SSI* of Arguments)
SSI#
N/A SWR? SWR=Boot:xx.yy.
zz Bulk1:xx.yy.zz
Bulk2:xx.yy.zz
(see Description
of Arguments)
TIM= TIM? TIM=hhmmss
TIM? (see Description
TIM* of Arguments)
TIM#
N/A TMP? TMP=xxx
(see Description
of Arguments)
