SLM-5650A Satellite Modem
Appendix C
Command
Parameter (Instruction
Type Code and
Qualifier)
BERT Pattern PAT= 1 byte, value of 0
thru 8
Retrieve next 5 N/A 110 bytes
unread Stored
Events
Arguments for
Command or
Response to
Query
Command or Query.
BERT Pattern, where:
0=2047
1=Mark
2=Space
3=1:1
4=1:2
5=2^15-1
6=2^20-1
7=2^23-1
8=MIL-188
Example: PAT=0 (2047 Pattern)
Query only.
Unit returns the oldest 5 Stored Events which have not yet been read over the
remote control.
Reply format: {CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-
body, where Sub-body= Axxxxxxxxddmmyyhhmmss, A being the fault type where:
1=Unit
2=Rx Traffic
3=Tx Traffic
4=Info
xxxxxxxx is the Fault Code number, as in LUF?, TXF?, RXF?, or Info Code,
which is:
00000000=Power Off
00000001=Power On
00000002=Log Cleared
00000004=Global Config Change
00000005=NP Card Watch Dog Timer
00000006=NP Card Boot Timeout
00000007=Transec Card Boot Timeout
If there are less than 5 events to be retrieved, the remaining positions are padded
with zeros.
If there are no new events, the response is RNE*.
Description of Arguments
C–27
Revision 8
MN-SLM5650A
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
PAT= PAT? PAT=x
PAT? (see Description
PAT* of Arguments)
PAT#
N/A RNE? RNE={CR}Axxxxx
xxxddmmyyhhmm
ss{CR}Axxxxxxxx
ddmmyyhhmmss{
CR}Axxxxxxxxdd
mmyyhhmmss{CR
}Axxxxxxxxddmm
yyhhmmss{CR}Ax
xxxxxxxddmmyyh
hmmss
(see Description
of Arguments)
