SLM-5650A Satellite Modem
Network Processor (NP) Interface
Add New Route
Take care to accurately create and add new route entries. Existing routes can't be
modified. If a mistake is made when adding a new route entry, the incorrect entry
must be deleted, and then recreated and re-added.
Use this section to add a route entry to the route table. Enter the information, and click [Add
Entry] to add the route. The route is immediately added to the route table for processing.
Delete Route
Use this section to specify which route table entry to delete when a route is no longer needed, and
then click [Delete Entry] to delete that route table entry.
8.6.6.6.2 Routing | OSPF
Use this page to define the operating parameters for Open Shortest Path First routing.
OSPF Parameters
Item
OSPF
Area Network Address

Figure 8-27. Routing | OSPF page

Description / Setting
To control OSPF routing, set the interface as Disabled or Enabled.
Network address of an area. An area is a set of networks and hosts within an
Autonomous System (AS) that has been administratively grouped together.
8–41
Revision 8
MN-SLM5650A
