SLM-5650A Satellite Modem
Front Panel Operation
Utility: Firmware
Image#X: Bulk App M&C Mod Demod Decoder
Filters TxIntfc RxIntfc Turbo
Where Image #X denotes selection of Image#1 or Image#2, both images display similar
information – the Firmware number with revision letter (shown as 'x'), its release date
(shown as MM/DD/YY), and version (shown as #.#.#) may differ for each firmware load.
Information is displayed as follows:
Image#X Item
Bulk
App
M&C
Mod
Demod
Decoder
Filters
TxIntfc
RxIntfc
Turbo
Opt
Utility: Firmware
Current Active Image#2
Next Reboot Image#1 #2
Select Image #1 or #2, and then press [ENT].
To reboot the modem, cycle the power.
Information

Example
(The bulk is the sum of all the individual pieces) FW-0000030x, MM/DD/YY, #.#.#
FW-0000031 x, MM/DD/YY, #.#.#
FW-0000032 x, MM/DD/YY, #.#.#
FW-0000033 x, MM/DD/YY, #.#.#
FW-0000034 x, MM/DD/YY, #.#.#
FW-0000038 x, MM/DD/YY, #.#.#
FW-0000034 x, MM/DD/YY, #.#.#
FW-0000040 x, MM/DD/YY, #.#.#
FW-0000041 x, MM/DD/YY, #.#.#
FW-0000042 x, MM/DD/YY, #.#.#
FW-####### x, MM/DD/YY, #.#.# (Varies depending on the installed optional interface)
Select

5–46
Image#X

(E)
(E)
Revision 8
MN-SLM5650A
