Comtech EF Data SLM-5650A Installation And Operation Manual page 204

SLM-5650A Satellite Modem
Network Processor (NP) Interface
Item
Area Subnet Mask
OSPF Area
Cost
Retransmit Interval
Transmit Delay
Priority
Hello Interval
Dead Interval
Authentication Key
Message Digest Key
Description / Setting
Subnet mask of the Area Network.
The SLM-5650A NP Interface supports only one OSPF Area at a time. A group of
(adjacent) routers which cooperate by exchanging their routing data base for the
specified network range; i.e. an OSPF router will only send its database to other
routers that advertise that they are in the same area.
Valid range is from 0 to 4294967295.
Specify the explicit cost of sending a packet via this interface.
Valid range is from 1 to 65535.
Specify the number of seconds between link state advertisement retransmissions for
adjacencies belonging to an OSPF interface.
Parameters used to define the route to the destination network.
Valid range is from 1 to 65535 seconds.
Set priority to help determine the OSPF.
Valid range is 0 (default, or not designated) to 255.
Specify the length of time, in seconds, between the hello packets that are sent on an
OSPF interface.
Valid range is from 1 to 65535 seconds.
Set the number of seconds that a device's 'Hello' packets must not have been seen
before its neighbors declare the OSPF router down.
Valid range is from 1 to 65535 seconds.
Assign a specific password to be used by neighboring OSPF routers on a network
segment that is using OSPF's simple password authentication.
Enable OSPG MD5 authentication.
8–42
Revision 8
MN-SLM5650A
