SLM-5650A Satellite Modem
Introduction
1.3

SLM-5650A Features

The SLM-5650A incorporates the following features:
• MIL-STD-188-165A compliance (Types A, B, D, E, F);
• Intelsat IESS-308, -309, -310, and -315;
• A rugged, one-rack unit (1RU) enclosure;
• Low weight and low power dissipation;
• Selectable 70/140 MHz or L-Band (950 to 2000 MHz) IF interfaces;
• EIA-530/422 Data Interface (built-in, to 20 Mbps);
• EIA-613/HSSI Data Interface (built-in, to 51.84 Mbps);
• EIA-485/EIA-232 Interface for serial remote control;
• Ethernet Interface for remote control using Telnet, SNMP, HTTP, HTTPS, and SSH;
• Plug-in Data Interface supporting the optional Gigabit Ethernet, Network Processor (NP),
G.703, and LVDS modules;
• Asymmetrical Loop Timing;
• Data Source Bit Synchronization (Clock recovery for input data without an associated
transmit clock);
• Full-featured, built-in BER test-set;
• Electrical and Ethernet Rx constellation monitor;
• Adaptive Equalizer for high order modulation types;
• 64 kbps to 155.52 Mbps (Modulation-, code rate-, and interface-dependent);
• BPSK, QPSK, OQPSK, 8PSK, 8QAM, and 16QAM;
• FEC Rates: 5/16, 1/2, 2/3, 3/4, 5/6, 7/8, 21/44, 5/16, 17/18, .382, .456, .547, and 1/1;
• Viterbi and Reed-Solomon Codec;
• Turbo Product Codec (optional);
• Low-Density Parity Check (LDPC) coding in three block sizes: ULL, LL, and HP
(optional);
Direct Sequence Spread Spectrum (DSSS) (optional with LDPC).
•
• Sequential FEC (optional);
• Static Bridge, Router, and BPM (Bridge Point-to-Multipoint) Modes (via the optional NP
Interface);
• TRANSEC Encryption (optional);
• Firmware updating capability.
