SLM-5650A Satellite Modem
TRANSEC Module HTTPS Interface
HTTPS Interface pages, select Crypto Officer from the drop-down, then click [Go!].
Once the Login page appears, type in a valid Crypto Officer User Name and Crypto Officer
Password – the default for both is comtech – then click [Log On].
The TRANSEC Module User Name and Password are each restricted to a minimum
of 7 and a maximum of 25 characters, excluding: (ASCII Code 58), < (ASCII Code
60), > (ASCII Code 62), " (ASCII Code 34), and ~ (ASCII Code 126).
Once the User Name and Password are accepted, the SLM-5650A TRANSEC Module "home"
page (Figure 10-1) appears. Click any tab or hyperlink to continue.
While legacy IE browser versions ( e.g., Internet
Explorer 6.0), may be used, Comtech EF Data
Technical Support does not provide support services
for these older browsers. Should the user encounter
problems connecting to the secure web interface using
an older browser, follow this troubleshooting tip:
From the browser tool bar, go to the Tools | Internet
Options | Advanced tab, then under the Security
heading, use the available check boxes to disable the
Secure Sockets Layers (SSL 2.0 and SSL 3.0), then
enable the Transport Layer Security (TLS 1.0).
Remember to re-enable SSL once finished with
troubleshooting.
10.3.1 HTTPS Interface – Operational Features
See Sect. 7.2.3 HTTP Interface – Operational Features for an overview of the navigational and
operational features common with using this interface.
10.3.2 HTTPS Interface Menu Tree
The following menu tree illustrates the options available via the TRANSEC Module HTTPS
Interface:
Interface Navigator
Drop-down Menu
Crypto Officer
Modem Operator
Network Operator
To the left, as described in previously, the Interface Navigator Drop-down menu and its selections
(shown in green) allow secure access to one of the SLM-5650A's three distinct Web interfaces.
Once Crypto Officer (i.e., the TRANSEC Module HTTPS Interface) is selected, the interface's
four available navigation tabs (shown in blue) may be accessed:
Page Navigation Tabs
Home Admin
Home Config
Contact Update
Event
10–3
MN-SLM5650A
Stats Maint
Module Status Unit Info
