Http/Https (Web Server) Interfaces - Comtech EF Data SLM-5650A Installation And Operation Manual

SLM-5650A Satellite Modem
Ethernet-Based Management
6.3

HTTP/HTTPS (Web Server) Interfaces

The SLM-5650A's embedded Web Server application provides the user with an easy to use
interface to configure and monitor all aspects of the modem. At present, three independent Web
Server Interfaces are available for the SLM-5650A, each designed for optimal performance when
using the supported browsers:
• SLM-5650A Base Modem HTTP Interface (standard) – Requires Microsoft's Internet
Explorer 5.5 (or higher) via HTTP.
Network Processor (NP) HTTP/HTTPS Interface (optional) – Available when the
•
optional Network Processor (NP) Interface is installed. This interface requires
Microsoft's Internet Explorer 7.0 (or higher) and Mozilla Firefox 2.0 (or higher), via
HTTP or HTTPS (depending on the interface's security level setting).
TRANSEC Module HTTPS Interface (optional) – Available when the optional
•
TRANSEC Module is installed. This interface requires Microsoft's Internet Explorer 7.0
(or higher) and Mozilla Firefox 2.0 (or higher), via HTTPS.
All Web Server Interfaces are accessible by typing (depending on the interface and/or
management mode) "http://xxx.xxx.xxx.xxx" or "https://xxx.xxx.xxx.xxx" into the browser's
Address box (where "xxx.xxx.xxx.xxx" is the IP address of the modem or optional installed
interface):
For all interfaces, the user is prompted to type in a valid User name
and Password, whether via an integrated Web page or a dialog box
similar to the one shown to the right. For all interfaces, the default
for both is comtech.
Chapter 7. BASE MODEM HTTP INTERFACE
Chapter 8.5 NETWORK PROCESSOR (NP) HTTP/HTTPS INTERFACE
Chapter 10. TRANSEC MODULE HTTPS INTERFACE
6–4
Revision 8
MN-SLM5650A
