Connector Pinouts

13.2.1.1 "J1 | BAL DATA" Connector – DB-15F (G.703 Balanced)
Connector | REF DES
13.2.1.2 "J2" through "J4" Connectors – BNC (G.703 Unbalanced)
Table 13-2. 75Ω BNC Connectors (G.703 Unbalanced)
Connector | REF DES

Table 13-1. " J1 | BAL DATA" Connector Pinout

Pin #
9
10
11
J1 12
13
14
15
J2 Tx Data G.703 (Input)
J3
J4
Ext Clock Ref (Input)
G.703 (Non-D&I)
1 SD_A G.703
SD_B G.703
2 Ground
3 RD_A G.703
RD_B G.703
4 Ground
5
6
7
8
Description Characteristics
BNC 75Ω Female
Rx Data G.703
BNC 75Ω Female
(Output)
BNC 75Ω Female
13–3
Revision 8
MN-SLM5650A
Direction
In
In
–
Out
Out
–
