SLM-5650A Satellite Modem
Front Panel Operation
CONFIG: Remote
Network Proc
Ethernet IP Address/Range:
To edit the Network Processor Module's Traffic IP Address and Range (when the module is
in Single Address Mode), first use the  arrow keys to select the digit to edit, and then use
the  arrow keys to edit the value of that digit. Press [ENT] when done.
CONFIG: Remote
Network Proc
Ethernet IP Address/Range:
To edit the Network Processor Module's Management IP Address and Range (when the
module is in Dual Address Mode), first use the  arrow keys to select the digit to edit,
and then use the  arrow keys to edit the value of that digit. Press [ENT] when done.
EthernetConfig

Traffic IP

192.168.001.054/24
EthernetConfig

Mgmt IP

192.168.002.072/16
5–33
Option Card Addr

(E)
Option Card Addr

(E)
Revision 8
MN-SLM5650A


