Comtech EF Data SLM-5650A Installation And Operation Manual page 385

SLM-5650A Satellite Modem
Appendix C
Command Arguments for
Parameter (Instruction
Type Code and
Qualifier)
ASYNC ESC ARB= 1 byte
Rx Baud Rate
ASYNC ESC ARF= 2 bytes
Rx Format
AUPC Log ASI= 1 byte
Sample Interval
Command or
Response to
Query
Command or Query.
Baud Rate, where:
0=110
1=150
2=300
3=600
4=1200
5=2400
6=4800
7=9600
8=19200
9=38400
Example: ARB=0 (sets the ASYNC ESC Rx Baud Rate to 110 Baud)
Command or Query.
Async Format, where:
00=7 Bits, No Parity, 1 Stop Bit
01=7 Bits, Even Parity, 1 Stop Bit
02=7 Bits, Odd Parity, 1 Stop Bit
03=7 Bits, No Parity, 2 Stop Bits
04=7 Bits, Even Parity, 2 Stop Bits
05=7 Bits, Odd Parity, 2 Stop Bits
06=8 Bits, No Parity, 1 Stop Bit
07=8 Bits, Even Parity, 1 Stop Bit
08=8 Bits, Odd Parity, 1 Stop Bit
09=8 Bits, No Parity, 2 Stop Bits
10=8 Bits, Even Parity, 2 Stop Bits
11=8 Bits, Odd Parity, 2 Stop Bits
Example: ARF=0 (sets the ASYNC ESC Rx Format to 7N1)
Command or Query.
Used to set the sample interval for the AUPC Logging Function in the form x, where:
x = 0 to 9 in 10 minute steps.
Note: Setting this parameter to 0 disables the logging function.
Example: ASI=3 (sets the logging inverval to 30 minutes)
Description of Arguments
C–33
Revision 8
MN-SLM5650A
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
ARB= ARB? ARB=x
ARB? (see Description
ARB* of Arguments)
ARB#
ARF= ARF? ARF=xx
ARF? (see Description
ARF* of Arguments)
ARF#
ASI= ASI? ASI=x
ASI? (see Description
ASI* of Arguments)
ASI#
