Chapter 3. REAR PANEL
CONNECTORS
PINOUTS
A ND
3.1
Overview
The SLM-5650A rear panel connectors (Figure 3-1) provide all necessary external connections
between the modem and other equipment. Table 3-1 on the next page summarizes the connectors
provided here, grouped according to service function.
Figure 3-1. SLM-5650A Rear Panel
3–1
