SLM-5650A Satellite Modem
Network Processor (NP) Interface
8.6.6.4.3 LAN | ARP (ARP Table)
ARP Table (Edit Static ARPs)
This table displays all current ARP entries (both Static and Dynamic). The current Static ARPs
may be directly edited here:
Column
Index
IP
MAC
Type
Click [Submit Changes] to save all changes made in this section.
Add Static ARP
Use this section to directly add a Static ARP entry, and then click [Add Entry] to add the entry.
Note that the index will automatically increment to the next available number.
Delete Static ARP
Enter Entry Index to Delete: Type in the Index number, and then click [Delete Entry] to
execute removal of the entry.

Figure 8-22. LAN | ARP page

Description
Displays the internal table index (read-only, cannot be edited).
Entry IP Address, format XXX.XXX.XXX.XXX
Entry MAC Address, format YY:YY:YY:YY:YY:YY
Displays the Entry Type as Static or Dynamic (read-only, cannot be edited)
8–36
Revision 8
MN-SLM5650A
