SLM-5650A Satellite Modem
Appendix C
Command
Parameter (Instruction
Type Code and
Qualifier)
Equipment ID N/A 17 bytes
Initialize Events IEP= None
Pointer
Software Image IMG= 1 bytes, value of
1 or 2
Arguments for
Command or
Response to
Query
Query only.
Unit returns information concerning the equipment identification, and the option field,
in the form aaaabcdefghijklmx where:
aaaa = defines the modem model number (565A = SLM-5650 in this case)
b = Advanced FEC: 0 = None, 1 = TPC, 2 = TPC + LDPC
c = Advanced FEC Data Rate: 0 = Base (5,000 kbps),
1 = 10,000 kbps, 2 = 20,000 kbps, 3 = 51,840 kbps, 4 = 155,520 kbps,
5 = 2,500 kbps
d = Option Card: 0 = None, 1 = G.703, 2 = GigaBit Ethernet,
4 = Network Processor, 5 = LVDS
e = Data Rate (Asymmetric Tx) Option: 0 = Base (5,000 kbps),
1 = 10,000 kbps, 2 = 20,000 kbps, 3 = 51,840 kbps,
4 = 155,520 kbps, 5 = 2,500 kbps
f = Higher-order modulation: 0 = None, 1 = 8PSK, 2 = 8PSK and 16QAM,
3 = 8PSK+16QAM and 16APSK/32APSK
g = Reed-Solomon Codec Option: 0 = None, 1 = Installed
h = Transec Module: 0 = None, 1 = FEC2 Card and Transec Module Installed,
i = AUPC Option: 0 = None, 1 = Installed
j = ASYNC Engineering Service Channel: 0 = None, 1 = Installed
k = Demod Only
l = CnC Data Rate: 0 = None, 1 = up to 512 kbps, 2 = up to 1 Mbps,
3 = up to 2.5 Mbps, 4 = up to 5 Mbps, 5 = up to 10 Mbps, 6 = up to 15 Mbps,
7 = up to 20 Mbps, 8 = up to 25 Mbps, 9 = up to 30 Mbps, A = up to 40 Mbps,
B = up to 51.840 Mbps, C = up to 70 Mbps
m = Sequential Encoding/Decoding Option: 0 = None, 1 = Installed
x = Asymmetric Rx Data Rate: 0 = None, 1 = 10,000 kbps, 2 = 20,000 kbps,
3 = 51,840 kbps, 4 = 155,520 kbps, 5 = 2,500 kbps
Example: EID=565A0000000000000 indicates SLM-5650A with no options installed
Command only.
Resets internal pointer to allow RNE? queries to start at the beginning of the stored
events log.
Command or Query.
Next Reboot Image, where:
1 = Bulk Image #1
2 = Bulk Image #2
Example: IMG=1 (Image #1 will be active after next reboot)
Description of Arguments
2 = FEC2 Card Installed (No Transec)
C–24
Revision 8
MN-SLM5650A
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
N/A EID? EID=aaaabcdefghi
jklmx
(see Description
of Arguments)
IEP= N/A N/A
IEP#
IMG= IMG? IMG=x
IMG? (see Description
IMG* of Arguments)
IMG#
