SLM-5650A Satellite Modem
Appendix C
C.6.6 Automatic Uplink Power Control (AUPC) Commands / Queries
The instruction codes that follow are valid only when the SLM-5650A Satellite Modem type has been set to AUPC.
Note: Always wait three (3) seconds between consecutive remote modem command/query polls. If Local AUPC is not enabled, queries will return
the last known condition. A request for status from the remote modem will then be transmitted, ensuring that the next query will return current status.
Command Arguments for
Parameter (Instruction
Type Code and
Qualifier)
ASYNC ESC ACT= 1 byte
Type
AUPC Eb/N0 AET= 4 bytes
Target Set Point
AUPC Minimum AMN= 5 bytes
Power Level
AUPC AMT= 3 bytes
Maximum
Tracking Rate
AUPC AMX= 5 bytes
Maximum
Power Level
AUPC Nominal ANP= 5 bytes
Power Level
Command or
Response to
Query
Command or Query.
ASYNC ESC Type, where:
0=RS-232
1=RS-485 2-Wire
2=RS-485 4-Wire
Example: ACT=0 (sets the ASYNC ESC to RS-232)
Command or Query.
AUPC Eb/N0 Target, where:
xx.x = AUPC Eb/N0 Target, 3.2 to 16.0 dB.
Example: AET=13.4
Command or Query.
Minimum Tx Output power level, where:
s=sign ( + / – )
xx.x = Tx Output power level, +10.0 and –40.0 dBm.
Example: AMN = –13.4
Command or Query.
AUPC Maximum Tracking Rate, where:
x.x = Maximum Tracking Rate, 0.5 to 6.0 dBm/minute in increments of .5.
Example: AMT=0.5
Command or Query.
Maximum Tx Output power level, where:
s=sign ( + / - )
xx.x = Tx Output power level, +10.0 and –40.0 dBm.
Example: AMX=-13.4
Command or Query.
Nominal Tx Output power level, where:
s=sign ( + / - )
xx.x = Tx Output power level, +10.0 and –40.0 dBm.
Example: ANP=-13.4
Description of Arguments
C–32
Revision 8
MN-SLM5650A
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
ACT= ACT? ACT=x
ACT? (see Description
ACT* of Arguments)
ACT#
AET= AET? AET=xx.x
AET? (see Description
AET* of Arguments)
AET#
AMN= AMN? AMN=sxx.x
AMN? (see Description
AMN* of Arguments)
AMN#
AMT= AMT? AMT=x.x
AMT? (see Description
AMT* of Arguments)
AMT#
AMX= AMX? AMX=sxx.x
AMX? (see Description
AMX* of Arguments)
AMX#
ANP= ANP? ANP=sxx.x
ANP? (see Description
ANP* of Arguments)
ANP#
