CDM-570/570L Satellite Modem with Optional IP Module
IP Module CLI and Telnet Operation
17.2

Main Menu Page

Menu pages are followed by a table listing the Menu Options/Fields, required Entry, and
Descriptions.
The Main Menu page has the following options/fields:
Menu Options/Fields
Administration
Interface Configuration
QoS Configuration
Route Table
Protocol Configuration
Vipersat Configuration
Entry
A The Administration menu provides a basic set of
standard admin functions to the
connected via telnet, navigation to this menu will be
restricted to the admin user.
I Allows the user to configure the Ethernet and Satellite
interfaces.
Allows the user to define QoS rules for up to 32
Q
different types of flows.
R
Allows a user to define how the
packets that it receives on its Ethernet and Satellite
interfaces.
P The Protocol Settings option allows the user to
configure various protocols used by the
These protocols currently include ARP and IGMP.
V Only used when the CDM-570/570L is used in a
Vipersat system.
17–3
MN/CDM570L.IOM
Description
IP M
odule. When
IP M
odule will route
IP M
Revision 3
odule.
