SLM-5650A Satellite Modem
TRANSEC Module SSH CLI Operation
11.2.7

Unit Info [ I ]

See Chapter 4. FLASH UPGRADING for detailed information on the procedures
associated with the TRANSEC Module firmware update process.
The Unit Information page, opened from the Main Menu, provides information needed to verify
that the correct firmware is loaded for operation of the unit. Note the following options or fields:
Menu Options/Fields
[Bootrom Info]
[Bulk 1 Info]
[Bulk 2 Info]
Boot From
Reboot
Entry Description
Displays the bootrom firmware.
[RO]
Displays the firmware version loaded into the Slot 1 location.
[RO]
Displays the firmware version loaded into the Slot 2 location.
[RO]
Selects the firmware boot source for modem operations as follows:
0 – Newest (automatically selects the most current version firmware
residing in either Slot 1 or Slot 2);
B
1 – Slot 1 (selects the firmware residing in the Slot 1 location;
2 – Slot 2 (selects the firmware residing in the Slot 2 location.
Note: If the 'Boot From' selection is changed, the user must reboot the
modem in order for that firmware selection to be loaded for operation.
Reboots the modem. When selected, the following message displays:
This action will reboot the TRANSEC module.
Are you sure? (Y/N)
Enter 'Y' or 'N'. If 'Y' is entered, the reboot process begins by closing the
SSH CLI. On the SLM-5650A front panel VFD, three messages will display
at minimum (depending on the modem's installed options):
THIS MODEM WILL REBOOT
R
IN FIVE SECONDS!
BOOTING MODEM...
...PLEASE WAIT
INITIALIZING MODEM...
Once the modem reboots, the user must initialize a new SSH CLI session to
resume use of this interface.
11–15
Revision 8
MN-SLM5650A
