SLM-5650A Satellite Modem
NP Interface Telnet/SSH CLI Operation
9.2.7 WAN Menu page (W)
The WAN Menu page, opened from the Main Menu, contains the following options or fields:
Menu Options/Fields
QoS Feature
Global Config & Statistics
Global Con Display
Global Statistics
Class Selector 6
Expedited Forwarding
Assured Forwarding Class 1
Assured Forwarding Class 2
Assured Forwarding Class 3
Assured Forwarding Class 4
Default
Clear (reset) Statistics
Entry Description
Prompts user to select:
Q
0 – Disabled
G
A
B
C
See Chapter Sect. 8.6.6.5 WAN Pages for an overview of
E
command functionality and/or information presented for these
functions.
1
2
3
4
D Provides user with read-only display of the DiffServ default queue.
R
Allows user to reset all DiffServ statistics.
9–25
Revision 8
MN-SLM5650A
1 – Enabled
