Table 4-8 shows the workflow for active/cold replacement of the XSCFU.
Table 4-8 Active/Cold Replacement Procedure of the XSCFU
Work Task
Order
1 Checking the operating condition of the
system and the I/O device usage status
2 Confirming the XSCFU to be replaced
3 Confirming that the XSCFU to be
replaced is the standby or slave XSCF and
is currently replaceable (*1)
4 Checking the logical domain assignment
status of CPU resources mounted in the
SPARC M12-2S requiring maintenance
5 Checking the logical domain assignment
status of memory resources mounted in
the SPARC M12-2S requiring maintenance
6 Releasing I/O resources of the SPARC
M12-2S requiring maintenance from a
logical domain
7 Releasing the SPARC M12-2S requiring
maintenance from the physical partition
8 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration
9 Placing the SPARC M12-2S requiring
maintenance into the cold state
10 Removing the XSCFU from the SPARC
M12-2S
11 Switching the SD card (*2)
12 Installing the XSCFU in the SPARC
M12-2S (*3)
13 Placing the SPARC M12-2S that required
maintenance into the hot state
14 Incorporating the SPARC M12-2S that
required maintenance into the building
block configuration
15 Confirming that there is no problem with
the replacement XSCFU
16 Incorporating the SPARC M12-2S that
required maintenance into the physical
partition
Reference
"9.2 Checking the Operation Status and
Resource Usage Status of Oracle
"8.2 Troubleshooting"
"Table 2-16 XSCFU LEDs and Their
States"
"3.2.4 Checking the Assignment Status
of Resources" in the Fujitsu SPARC M12
and Fujitsu M10/SPARC M10 Domain
Configuration Guide
"3.2.4 Checking the Assignment Status
of Resources" in the Fujitsu SPARC M12
and Fujitsu M10/SPARC M10 Domain
Configuration Guide
"9.3 Releasing I/O Resources From a
Logical Domain"
"9.4.3 Dynamically Releasing the
SPARC M12-2S From the Physical
Partition"
"9.6.1 Releasing the SPARC M12-2S
From the Building Block Configuration"
"9.8.2 Removing the Power
"11.4 Removing the XSCFU"
"11.5 Switching an SD Card"
"11.6 Installing the XSCFU"
"10.1.1 Installing a Power
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
"10.5.3 Checking the FRU Status After
Maintenance"
"10.6.1 Incorporating the SPARC
M12-2S Into the Physical Partition Using
PPAR DR"
Chapter 4 FRU Replacement Workflows
Solaris"
Cords"
Cord"
