Table 5-21 System-Stopped/Hot Addition Procedure of a PCI Expansion Unit
Work
Task
Order
1
Checking the operating condition of the
system
2
Powering off all physical partitions
3
Switching the mode switch on the OPNL
to Service
4
Removing the PCICS from the SPARC
M12-2/M12-2S
5
Removing the PCIe card filler from the
PCICS
6
Installing a link card in the PCICS to
install it in the SPARC M12-2/M12-2S
7
Connecting a PCI expansion unit to the
link card
8
Installing a PCIe card in the PCI
expansion unit.
9
Diagnosing the SPARC M12-2/M12-2S
that is connected to the added PCI
expansion unit
10
Confirming that there is no problem with
the added PCI expansion unit
11
Switching the mode switch on the OPNL
to Locked
12
Powering on all physical partitions
13
Assigning the I/O resource to a logical
domain
Reference
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical
"9.5.2 Stopping All Physical
"2.3.2 OPNL Control
Function"
"12.3.1 Enabling the Removal of a PCIe
Card"
"12.3.2 Removing a PCIe Card or PCIe
Card
Filler"
"12.4.1 Installing a PCIe Card or PCIe
Card
Filler"
"4.2 Connecting Cables to the PCI
Expansion Unit" in the Fujitsu SPARC
M12-2 Installation Guide
or
"5.2 Connecting Cables to the PCI
Expansion Unit" in the Fujitsu SPARC
M12-2S Installation Guide
"12.4.1 Installing a PCIe Card or PCIe
Card
Filler"
"10.5.1 Diagnosing the SPARC M12
Hardware"
"10.5.3 Checking the FRU Status After
Maintenance"
"2.3.2 OPNL Control
Function"
"10.9.1 Starting the System With an
XSCF
Command"
"3.2 Operations and Commands Related
to Logical Domain Configurations" in the
Fujitsu SPARC M12 and Fujitsu
M10/SPARC M10 Domain Configuration
Guide
Chapter 5 FRU Addition Workflows
Domains"
Partitions"
179
